Contura C i5AN Installation Instruction page 14

GB
126
STAND ASSEMBLY
5
!
Ensure that the disc base can be pushed around the
stand. Adjust the base height with the rubber feet. On
heavily sloping floors the insert and stand may need to
be raised further.
Then reposition the base until all stones are in place.
Check that there is a 30 mm gap all the way between
the rear of the stand and wall behind.
• With protective screen as option –
now install according to separate instructions.
• Connect chimney –
upwards or rearwards, follow the chimney
manufacturer's instructions.
• With Powerstone as option –
position the heat tank according to the insert's
instructions.
x 8
M4 x 6
T20
6
m
M i n 3 0 m
m m
3 0
M i n
