INSTALLATION

26
Installation
Ensure that the installation is approved by a certified chimney
sweep, who can also provide information on which national and
regional regulations apply. Also ensure that a function check of
the hatch opening mechanism and damper control is performed
according to the "Function check" section.
Supply of combustion air
Combustion air can be provided directly via a
duct from outside, or indirectly via a vent in
the outer wall of the room where the stove
is to be placed. The amount of combustion
air that is used for combustion is approx. 30
m3/h.
Some installation alternatives are shown to
the right.
The air duct connection on the stove has
an external diameter of Ø100 mm. In hot
areas, the duct should be insulated with 30
mm mineral wool covered with a moisture
inhibitor for example, aluminium tape.
It is important that the lead-in between the
pipe and the wall (or floor) is sealed using
jointing compound.
A 1 m length of condensation insulated
ducting for combustion air is available as an
accessory.
HK
HK
Alt. 1 Alt. 2
HK
HK
