Installation distances

C 630
Combustible roof
551
Combustible wall
700
Permitted area
for combustible
550
parts of the
building
570
850
* If the stove is placed on a hearth plate made of glass for example (accessory), the height from the floor is affected by a distance corresponding to the thickness of the hearth plate. Also applies to
separate glass hearth plates (accessory).
** To prevent discolouration of painted non-flammable walls we recommend that the same side distance as to combustible walls is used.
WHEN INSTALLING TURNTABLE (OPTION)
following installation distances do not apply.
See the separate turntable installation
instructions.
Ø150
Combustible wall
the
478
151
40
92
100
Air inlet Ø67
630
Fire-retardant wall of
brick or concrete
615
800
Fire-retardant wall of
brick or concrete
200**
480
INSTALLATION DISTANCES
The minimum distance in front of
the stove opening to combustible
parts of the building or interior
decoration must be at least 1 m.
When top connecting a steel flue,
please refer to the particular
manufacturer's installation
instructions. Observe the safety
distance to combustible material
required by the steel flue
A = height from floor to chimney
connection upwards
B = height from floor to c/c
chimney connection rear
C = height from floor to air inlet
D = height from floor to bottom
edge door
!
A separate glass hearth
plate (accessory)
increases the connection
height to the chimney
by 10 mm. The spacers
supplied with the hearth
plate are installed on the
stove before connection.
