Connection to chimney

The insert is prepared for top connection, when connecting from
the rear of the insert, the Ø200 connector and cover on the rear
of the insert must be switched over, see "Connecting from the
rear of the insert".
When connecting to the chimney of less than Ø200, install a
reduction pipe on the existing Ø200 connector. The reduction
pipe must not have an exit diameter less than Ø150. When using
reduction pipes, flue gases can be forced out into the room if the
insert is lit with the hatch open. The condition for connecting to
a Ø150 chimney is that the insert must only be lit with the hatch
closed.
Rear connection to a masonry chimney
Mark out the centre for making a hole in the wall to the flue.
Check that the connection height in the chimney breast
corresponds to the height of the connection pipe from the stove.
Make a hole large enough so that the wall connector can be
cemented in position with fireproof mortar (not supplied). Let the
mortar dry before the insert is connected to the chimney.
IMPORTANT
Always observe the safety distances to
combustible material that steel flues
require
