Stratasys Dimension BST 1200 Troubleshooting Manual page 23

Dimension BST 1200 / SST 1200 Service Guide
4. Burn marks in part
4. Yellow Streaks in Part
5. Part Fell Over
6. Wavy Roads
7. Part Curl
8. Part shifts in the Z Direction
9. Wavy parts
10. Underfill
11. Model material sagging on curved parts
1. Check tip wipe brush and flicker.
2. Replace Tip Shroud
3. Loose tip.
4. Material build-up behind the tip - remove excess material
1. Re-Orient part
1. Run Z-Calibration.
2. Reprocess - Resend part
3. Overfill / part curl / unstable geometry
4. Bad Z motor - test with HyperTerminal and running the TZ command.
1. Problem with XY table - Check belt tension and bearings.
2. Reprocess STL at a higher resolution
1. Part is too dense - try "Sparse" fill
2. Re-run Z Calibration
3. Check that all chamber fans are working
4. Check for loose heater covers
5. Verify the chamber temperature using a thermometer
1. Check that lead screw is clean and well lubricated
2. Binding Z stage nuts -replace nut.
3. Bad Z motor - test with HyperTerminal and running the TZ command.
4. Z drive belt is worn or loose
1. X or Y Motor issue - replace motors
2. Replace Toggle plate Assembly
3. Idler pulley problem - replace XY table
4. Reprocess STL at a higher resolution
1. Install a new material cartridge.
2. Replace tips
3. Reprocess part using CatalystEX default settings
4. Check to make sure Work Station is running the latest version CatalystEX
5. Inspect for Spaghetti Head
6. Replace head board
Change material.
Page 8-23
Troubleshooting
