2 Ethernet NetMask
3 Ethernet MAC
4 Ethernet Gateway
5 Streaming Mode
6 Streaming I/F
Wi-Fi RXID
7
(multicast)
8 Wi-Fi SSID
9 Wi-Fi Quality
10 Group IP
11 Peer IP(lan)
12 Peer Machine
13 Peer S/W version
14 Local Machine
15 Local S/W version
16 Submit
17 Refresh
Distributed by Pera Systems, Inc.
R/W Subnet mask of the decoder IP address
R Mac Address
R/W Gateway of Sub-network
P2P: Point to point mode. Streaming from Ethernet IP
IP⑧
R/W
Multicast: Point to multi-point mode, Streaming from one TX to
many RXs with the multicast address⑦.
R Selection of streaming interface: Ethernet LAN
Current receiver ID selected on the front panel of the
WiMi6200R. There can be maximum 4 receivers for one
transmitter when the system is operating in Wi-Fi mode. This
R
Wi-Fi RXID is used to identify specific RX from the TX. The one
value must be assigned to the only one receiver in one Wi-Fi
network with same SSID.
Current SSID selected on the front panel of the WIMi6200R.
R
This value must be same with the SSID of the WiMi6200T.
R Wi-Fi signal strength received at this WiMi6200RW
Multicast IP address used for receiving A/V data from the
R/W
WiMi6200T. Default multicast IP address is 227.2.2.7.
IP Address of peer encoder. Default & factory setting IP address
R/W
of the encoder is 192.168.0.161.
The status of the peer machine, such as P2P or Multicast ,and
R
its IP address
R The software version of the peer encoder machine
R The status of the local machine, such as P2P or Multicast
R The software version of the local machine, WiMi6200R
All the values on this web page will be written to the system
W
when this button is clicked.
All the values of the system on this web page will be read from
R
the system and displayed when this button is clicked.
