5,6,7 Video Signal
8 Streaming
9 Restart Streaming
10 Forced Enc Res
11 Encapsulation
12 RTSP Server
Distributed by Pera Systems, Inc.
If video is not connected, the Video Signal will show "not
R
detected" only without any displays of
R Status about audio, video and streaming server
W Restarts streaming
Selection of forced encoding resolution to be encoded on the
WiMi6200T.
- WiMi6200T supports downscale only, so the resolutions that
is smaller than input resolution will be listed in the drop
box.
- WiMi6200T cannot make more frames than input signal. If
you select a frame rate which is larger than input frame rate,
then WiMi6200T will encode by input frame rate and
WiMi6200R will display to the selected frame rate.
R/W
- WiMi6200T cannot convert progressive video to interlaced
video, or vice versa. Only same scanning resolutions are
listed in the drop box.
- Irrespective of this selection, if the selected signal is not
possible to be displayed on current output port of
WiMi6200R, or the monitor on RX side cannot accept it
then, the WiMi6200T will encode the video to another
resolution.
Input means no forced encoding with specific resolution.
Selection of the encapsulation method of RTSP or MPEG-TS for
the streaming server.
RTP: RTP encapsulation mode. This is normal video streaming
mode for WiMi6200R decoding and the RTSP client (software
R/W decoder) such as, VLC player or etc.
TS2UDP: MPEG-TS encapsulation mode. The WiMi6200T will
stream video as the MPEG-TS format with the 48kHz linear
PCM audio. If the TS2UDP is selected, the WiMi6200R can
decode the video from the WiMi6200T.
This button will be displayed when the RTP is selected in the
Encapsulation. Turn RTSP server ON for RTSP streaming
R/W server mode. In the RTSP server mode, the video from
WiMi6200T can be decoded in the WiMi6200R as well as RTSP
client, simultaneously
