3.4.1.2 Serial Port Configuration
Item List
1 Baudrate
2 Stop Bit
3 Character Size
4 Parity
5 Flow Control
6 Submit
7 Refresh
Distributed by Pera Systems, Inc.
R/W
R/W Set baud rate of serial port: 1200 - 115200
R/W Stop bit: 1 or 2
R/W Character size: CS5 (5-bit) - CS8 (8-bit)
R/W Parity: Odd, Even, Disable
R Flow Control
All the values on this web page will be written to the system
W
when this button is clicked.
All the values of the system on this web page will be read from
R
the system and displayed when this button is clicked.
Page 36
WiMi6200 User's Manual
Description
v1.2
