2. Installation
2.1 Video Signal Connections
WiMi6200T

 Connect the video cable from the SDI/HD-SDI camera or other SDI/HD-SDI video
source to the SDI video connector.
WiMi6200R

 Connect the video/audio cable from the SDI/HD-SDI video connector to the
display device.
2.2 Audio Signal Connections
 WiMi6200T
 Audio input
 Input HD-SDI port includes embedded digital audio data.
 Aux. Audio In: Connect the mini stereo phone cable from microphone,
 Aux. Audio Out: Connect the mini stereo phone cable from this jack to the
WiMi6200R

 Audio output
 Output HD-SDI port includes embedded digital audio data.
 Main Audio Out: Connect the mini stereo phone cable from this jack to the
 Aux. Audio In: Connect the mini stereo phone cable from microphone,

Distributed by Pera Systems, Inc.
microphone of the headset or other audio source to this jack. Analog audio
input is converted to 8kHz 16-bit digital audio for transmitting to the Aux.
Audio Out port of the WiMi6200R.
speaker or headset. This analog audio output is the analog audio that is
received from the Aux. Audio Out port of the remote WiMi6200T.
speaker or to other audio input device. This analog audio output is
converted from 48kHz 16-bit digital audio that is received from the
embedded audio from the SDI port of the WiMi6200T.
microphone of the headset or other audio source to this jack. Analog audio
input is converted to 8 kHz 16-bit digital audio for transmitting to the Aux.
Audio Out port of the WiMi6200T.
Aux. Audio Out: Connect the mini stereo phone cable from this jack to the
speaker or headset. This analog audio output is the analog audio that is
received from the Aux. Audio Out port of the remote WiMi6200R.
