3.4.1.4 Streaming Control
Item List
1 Peer Video Out Port
Peer Output
2
Resolution
3 Video In Port
4 Audio In Port
5 Video Signal
6 Resolution (In/Enc)
7 Color Space
Distributed by Pera Systems, Inc.
R/W
R Video output port information of the decoder
R Video output resolution information of the decoder
R Current input video port
R Current input audio port
Shows the status of input Video Signal. If the video signal is
detected, then the item
R
not connected, the Video Signal will show "not detected"
only without any displays of
Resolution information of the input video signal, if detected.
R The first one is the information of the input video signal, and
the latter is the information of the encoded video.
R Color space information of the input video signal, if detected.
Page 43
WiMi6200 User's Manual
Description
⑥⑦⑧
will be displayed. If video is
⑥⑦⑧.
⑨
