Nimbus Water Systems WIMI6200 User Manual page 35

Item List
1 Ethernet IP
2 Ethernet NetMask
3 Ethernet MAC
4 Ethernet Gateway
5 Streaming Mode
6 Streaming I/F
7 Wi-Fi Channel
8 Wi-Fi SSID
9 Wi-Fi Status
10 Group IP
11 Peer IP
12 Multicast TTL
13 Peer Machine
14 Peer S/W version
15 Local Machine
16 Local S/W version
17 Submit
18 Refresh
Distributed by Pera Systems, Inc.
R/W
IP address of the encoder. Default & factory setting IP address
of the encoder is 192.168.0.161. The IP address can be changed
R/W to any IP by clicking Submit
changed to other value, then you have to enter changed IP
address on the URL field of the web.
R/W Subnet mask of the encoder IP address
R Mac Address
R/W Gateway of Sub-network
P2P: Point to point mode. Streaming from Ethernet IP
IP ○
11
E
R/W A
Multicast: Point to multi-point mode, Streaming from one TX to
many RXs with a multicast address
R Current streaming interface: Wi-Fi or Ethernet LAN
Current Wi-Fi channel frequency, 36(5180MHz), 44(5220MHz),
R
149(5745MHz), 157(5785MHz)
R Current SSID of the transmitter
R Current Wi-Fi operation status
Multicast IP address
R/W
Default multicast IP address is 227.2.2.7.
IP Address of Decoder. Default & factory setting IP address of
R/W
the decoder is 192.168.0.162.
Time to live value of IP when system is running at multicast
R/W
mode.
The status of the peer machine, such as P2P or Multicast ,and
R
its IP address
The software version of the peer decoder machine, if the peer
R
machine is a WiMi6200R decoder
R The status of the local machine, such as P2P or Multicast
R The software version of the local machine, WiMi6200T
All the values on this web page will be written to the system
W
when this button is clicked.
All the values of the system on this web page will be read from
R
the system and displayed when this button is clicked.
Page 34
WiMi6200 User's Manual
Description
○ button. If the IP address is
13
E
A A
○ .
10
E
A A
○ to Peer
1
E
A A
v1.2
