Alvarion BreezeMAX Si 4000 CPE User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

zzAlvarion_ page
®
BreezeMAX
Si 4000 CPE

User Manual

Software Version: 2.0
December 2010
P/N 215801

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BreezeMAX Si 4000 CPE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alvarion BreezeMAX Si 4000 CPE

Summary of Contents for Alvarion BreezeMAX Si 4000 CPE

  • Page 1: User Manual

    zzAlvarion_ page ® BreezeMAX Si 4000 CPE User Manual Software Version: 2.0 December 2010 P/N 215801...

  • Page 2: Document History

    Document History Document History Topic Description Date Issued BreezeMAX Si 4000 CPE Manual This is the document’s first release. March 2010  General Ver.1.0M August 2010 For changes that require device reset, the device will automatically initiate reset after clicking the Apply button.
  • Page 3 New 3.3-3.4 GHz band “Setting Basic Parameters” Added Bridge-IPCS and Bridge-ETHCS Ver.2.0 November 2010 on page 44 support description “DHCP Server” on page 65 DHCP Ending IP Address default is Ver.2.0 November 2010 192.168.254.5 BreezeMAX Si 4000 CPE User Manual...
  • Page 4 © Copyright 2011 Alvarion Ltd. All rights reserved. The material contained herein is proprietary, privileged, and confidential and owned by Alvarion or its third party licensors. No disclosure thereof shall be made to third parties without the express written permission of Alvarion Ltd.
  • Page 5 BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING OR OTHER HAZARD. Disclaimer (a) The Software is sold on an “AS IS” basis. Alvarion, its affiliates or its licensors MAKE NO WARRANTIES, WHATSOEVER, WHETHER EXPRESS OR IMPLIED, WITH RESPECT TO THE SOFTWARE AND THE ACCOMPANYING DOCUMENTATION.

  • Page 6: Limitation Of Liability

    MAINTENANCE OR USE OF ITS PRODUCTS. Limitation of Liability (a) ALVARION SHALL NOT BE LIABLE TO THE PURCHASER OR TO ANY THIRD PARTY, FOR ANY LOSS OF PROFITS, LOSS OF USE, INTERRUPTION OF BUSINESS OR FOR ANY INDIRECT, SPECIAL, INCIDENTAL, PUNITIVE OR...

  • Page 7: Safety Information

    Radio Frequency Interference Statement The BreezeMAX Si 4000 CPE has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC rules and to EN 301 489-1 rules.
  • Page 8 Disposal of Electronic and Electrical Waste Pursuant to the WEEE EU Directive electronic and electrical waste must not be disposed of with unsorted waste. Please contact your local recycling authority for disposal of this product. BreezeMAX Si 4000 CPE viii User Manual...
  • Page 9 Safety Information BreezeMAX Si 4000 CPE User Manual...

  • Page 10: Important Notice

    It could also void the user's authority to operate the equipment. Some of the equipment provided by Alvarion and specified in this manual, is manufactured and warranted by third parties. All such equipment must be...
  • Page 11 Important Notice the manufacturers. Non-compliance with such instructions may result in serious damage and/or bodily harm and/or void the user's authority to operate the equipment and/or revoke the warranty provided by such manufacturer. BreezeMAX Si 4000 CPE User Manual...

  • Page 12: About This Manual

    About This Manual About This Manual This manual describes the BreezeMAX Si 4000 CPE and details how to install, operate and manage it. This manual contains the following chapters and appendices: Chapter 1 -  Product Description - Describes the BreezeMAX Si 4000 CPE unit ...

  • Page 13: Table Of Contents

    Chapter 2 - CPE Installation ..............15 2.1 Installation Requirements ..................17 2.1.1 Package Content....................17 2.2 Installation Procedure .....................18 2.2.1 Guidelines for Positioning the Unit ..............18 2.2.2 Installing the Unit....................18 2.3 BreezeMAX Si 4000 Hardware Description ............21 BreezeMAX Si 4000 CPE xiii User Manual...

  • Page 14: Contents

    4.6 Restore to Factory Default Configuration .............51 Chapter 5 - Configuring WiFi Parameters ..........52 5.1 Introduction ......................54 5.2 WiFi Configuration ....................55 5.2.1 Wireless Settings ....................55 5.2.2 Wireless Security ....................58 5.2.3 ACL (Access Control List) Settings ..............61 BreezeMAX Si 4000 CPE User Manual...
  • Page 15 8.2 Device Status ......................88 8.3 WiMAX Status ......................90 8.4 Software Status .......................95 8.5 Telephony Status .....................96 8.6 Certificate Status .....................97 8.7 About ........................99 Chapter 9 - Configuring Telephony Parameters ........ 100 VoIP Parameters ......................102 BreezeMAX Si 4000 CPE User Manual...
  • Page 16 Contents Chapter 10 - Troubleshooting............. 105 Glossary ....................110 BreezeMAX Si 4000 CPE User Manual...

  • Page 17: Chapter 1 - Product Description

    zzAlvarion_ page Chapter Product Description...
  • Page 18 Chapter 1 - Product Description In This Chapter: “Introducing the BreezeMAX Si 4000” on page 3  “Safety Information” on page 7  “Specifications” on page 8  BreezeMAX Si 4000 CPE User Manual...

  • Page 19: Introducing The Breezemax Si 4000

    WiFi access point service. The BreezeMAX Si 4000 unit also includes built-in WiMAX or two fold-out antennas for WiMAX communication. The following table lists the available BreezeMAX Si 4000 models: BreezeMAX Si 4000 CPE User Manual...
  • Page 20 2 VoIP phone port (RJ-11)  WiFi (802.11b/g) 3.3-3.6 GHz  4M-CPE4000-Si-1D-1V-3.5 1 data port (RJ-45)  1 VoIP phone port (RJ-11)  4M-CPE4000-Si-1D-1V-WiFi-3.5 1 data port (RJ-45)  1 VoIP phone port (RJ-11)  WiFi (802.11b/g) BreezeMAX Si 4000 CPE User Manual...

  • Page 21: Product Features

    Introducing the BreezeMAX Si 4000 4M-CPE4000-Si-1D-1V-2.5 The PREMIUM Model: 4M-CPE4000-Si-1D-1V-3.5 4M-CPE4000-Si-2D-2V-WiFi-2.5 4M-CPE4000-Si-1D-1V-WiFi-3.5 Figure 1-1: The BreezeMAX Si 4000 CPE 1.1.1 Product Features The BreezeMAX Si 4000 supports the following features: WiMAX 802.16-2005 Wave2 Standard Compliant Air Interface  WiFi (for specific models) ...
  • Page 22 Auto-provisioning with remote firmware upgrade  IEEE 802.3, IEEE 802.3u  Gateway mode  Bridge mode for Management and VoIP  IP-CS Bridge mode  ETH-CS Bridge mode  Voice over IP  VPN pass-through  BreezeMAX Si 4000 CPE User Manual...

  • Page 23: Safety Information

    Do not keep the device close to sensitive electronic equipment like TV, Radio,  Microwave ovens, etc. Do not keep the device near strong magnetic field generators.  BreezeMAX Si 4000 CPE User Manual...

  • Page 24: Specifications

    Recessed switch, rear panel 1.3.2 WiMAX Radio Table 1-3: WiMAX Radio Specifications Item Description Radio Type IEEE 802.16e 2005 WAVE 2 Frequency Band  2.5 GHz - 2485~2690 MHz  3.5 GHz - 3300~3600MHz BreezeMAX Si 4000 CPE User Manual...
  • Page 25 5 msec. RF Transmitter Specifications RF dynamic range 45dB minimum Transmit Power Control Relative mRCT compliant Accuracy Transmit and Receive Switching 50 S RF Receiver Specifications Impedance 50 ohms nominal Input return loss 10dBi BreezeMAX Si 4000 CPE User Manual...

  • Page 26: Wifi Radio

    2412 MHz - 2484 MHz (channels 1- 14) frequency) Channel Bandwidth 22 MHz Output Power@11g/54Mbps 15±1 dBm Security 802.1x, Shared Key, WPA, WPA2, WPA-WPA2-Mixed, WPA PSK, WPA2 PSK, WPA-WPA2-Mixed PSK Radio Technology Orthogonal Frequency Divisional Multiplexing (OFDM) BreezeMAX Si 4000 CPE User Manual...

  • Page 27: Voip Specifications

    Voice Codecs  g711 (a-law and u-law)  g729a/b  g723  ILBC Voice Quality  VAD (Voice Activity Detection)  Echo cancellation (G.168)  Adaptive jitter buffer  DTMF tone detection and generation BreezeMAX Si 4000 CPE User Manual...

  • Page 28: Configuration And Management

    Item Description Management options  Web-based (HTTP/HTTPS)  TR-069 1.3.6 Mechanical Table 1-7: Mechanical Specifications Item Description Dimensions 232(H)*142(W)*36(D) mm ,  Premium model: 253(H)*236(W)*165(D) mm Weight 0.59 or 0.65 (depending on model) kg BreezeMAX Si 4000 CPE User Manual...

  • Page 29: Electrical

    ETSI EN 301 489 Safety  UL 60950-1  IEC 60950-1  EN 60950-1 Radio  ETSI EN 302 623  ETSI EN 300 328  FCC 04-135, Part 15, 25, 27 EN 302 544  BreezeMAX Si 4000 CPE User Manual...
  • Page 30 Chapter 1 - Product Description Specifications Table 1-10: Standards Compliance Type Standard Standards  IEEE 802.16e-2005 WAVE 2  IEEE 802.3-2005 10BASE-T and 100BASE-TX  IEEE 802.3u  IEEE 802.11b and 802.11g BreezeMAX Si 4000 CPE User Manual...

  • Page 31: Chapter 2 - Cpe Installation

    zzAlvarion_ page Chapter CPE Installation...
  • Page 32 Chapter 2 - CPE Installation In This Chapter: “Installation Requirements” on page 17  “Installation Procedure” on page 18  “BreezeMAX Si 4000 Hardware Description” on page 21  BreezeMAX Si 4000 CPE User Manual...

  • Page 33: Installation Requirements

    This section describes how to install and connect the BreezeMAX Si 4000. 2.1.1 Package Content The BreezeMAX Si 4000package includes the following components: BreezeMAX Si 4000unit  RJ-45 Category 5 network cable (1.5m)  AC power adapter  Quick Installation Guide  BreezeMAX Si 4000 CPE User Manual...

  • Page 34: Installation Procedure

    Connect the power cable to the power jack located on the rear panel of the unit. Connect the other end of the power cord to the AC outlet. The unit will take 1-2 minutes to boot up and find a nearby base station signal. BreezeMAX Si 4000 CPE User Manual...
  • Page 35 Initiation Protocol (SIP) technology is used to make VoIP calls. You must access the web interface and configure settings for your SIP service provider before you can make VoIP calls. The VoIP service may be configured remotely or locally by web. BreezeMAX Si 4000 CPE User Manual...
  • Page 36 “Configuring the CPE Using the WiMAX Modem Application CD” on page Use your PC’s web browser to access the unit’s management interface and make any configuration changes. For more information, see “Commissioning” on page BreezeMAX Si 4000 CPE User Manual...

  • Page 37: Breezemax Si 4000 Hardware Description

    Table 2-1 Table 2-2 Table 2-3. Optimize the performance by placing the BreezeMAX Si 4000 where the greatest number of WiMAX signal strength lights are on. Try positioning the unit in different places to maximize signal strength. BreezeMAX Si 4000 CPE User Manual...
  • Page 38 * WiFi LED (3) in 3.5 GHz models, unused LED in 2.5 GHz models Premium model WiMAX Signal Strength LEDs (3-5) WiMAX LED (2) VoIP LEDs (7,8) WiFi LED (6) Power LED (1) Figure 2-1: BreezeMAX Si 4000 and BreezeMAX Si 4000 Premium Front Panel BreezeMAX Si 4000 CPE User Manual...
  • Page 39 CPE is not connected to a base station WiMAX Link Status (5) The greater the number of WiMAX link status lights are on, the better the performance. WiMAX Link Status (6) WiMAX Link Status (7) BreezeMAX Si 4000 CPE User Manual...

  • Page 40: Rear Panel

    The BreezeMAX Si 4000 Premium model includes two LAN ports for 10/100 Mbps Ethernet connection, two RJ-11 Voice over IP (VoIP) phone ports, and an AC power jack. The following table summarizes the BreezeMAX Si 4000 rear panel elements: BreezeMAX Si 4000 CPE User Manual...
  • Page 41 VoIP calls over the Internet. Power adapter Power socket Connection to 100-240 VAC at 50-60 Hz The following figures show the rear of BreezeMAX Si 4000 and the location of the ports. BreezeMAX Si 4000 CPE User Manual...
  • Page 42 RJ-45 LAN Port RJ-11 VoIP Phone Port Power Socket Premium Model RJ-11 VoIP Power Socket RJ-45 LAN Ports Reset button Phone Ports Figure 2-2: BreezeMAX Si 4000 and BreezeMAX Si 4000 Premium Rear Panel BreezeMAX Si 4000 CPE User Manual...

  • Page 43: Reset Button

    NOTE The length of the Ethernet cable connecting the BreezeMAX Si 4000 to the data equipment, must not exceed 100 meters. Use only Category 5E Ethernet cables from either Alvarion or any of the approved manufacturers, listed in Table 2-5. Consult with Alvarion's specialists on the suitability of other cables.

  • Page 44: Breezemax Si 4000 Wi-Fi Option

    PCs. To connect your PC using WiFi, click the WiFi icon (lower right corner of PC); Click Find WLAN and select the name of WiFi network Click Connect. BreezeMAX Si 4000 CPE User Manual...

  • Page 45: Chapter 3 - Commissioning

    zzAlvarion_ page Chapter Commissioning...
  • Page 46 “Introduction” on page 31  “Configuring the CPE Using the Web Management Interface” on page 33  “Configuring the CPE Using the WiMAX Modem Application CD” on page 36  “Operation Verification” on page 40  BreezeMAX Si 4000 CPE User Manual...

  • Page 47: Introduction

    Should be supplied by system realm, e.g: administrator. Configured in the 0026824EE12C@WiMax.com Advanced> Authentication window WiMAX Password quickynikynyoky wimax.com  Domain (also Eng > WiMAX Config > Realm Frequency Full Scan Should be supplied by system administrator. BreezeMAX Si 4000 CPE User Manual...
  • Page 48 Table 3-1: Basic Parameters Item Default Value Comment Telephony - SIP Server, phone Disabled Optional number, authentication, enable VoIP is disabled by default and should the phone be enabled by the operator WiFi Enabled Enabled by default BreezeMAX Si 4000 CPE User Manual...

  • Page 49: Configuring The Cpe Using The Web Management Interface

    Open a web browser and enter the default IP address: http://192.168.254.251. The web browser displays the login page. Figure 3-1: Login Window Enter the user name and password, and click Login. The default credentials are: » Username: admin » Password: admin BreezeMAX Si 4000 CPE User Manual...

  • Page 50: Applying Changes And Using Help

    Apply - Click this button to save the changes you have made in each page of  the device system. For changes that require device reset, the device will automatically initiate reset after clicking the Apply button. BreezeMAX Si 4000 CPE User Manual...
  • Page 51 Reconnect - Click this button to attempt reconnecting the device to the Base  Station. This step is normally not required, unless suspecting that connection is problematic. Help - Click this button to open context-sensitive on-line help.  BreezeMAX Si 4000 CPE User Manual...

  • Page 52: Configuring The Cpe Using The Wimax Modem Application Cd

    From the CDROM supplied with the unit, run the CPE Auto Configuration Tool: CPEAutoConfigTool.exe; The Installation Setup Wizard window is displayed. Figure 3-3: Installation Setup Wizard Window Click Next to continue; The Choose Your ISP window is displayed. BreezeMAX Si 4000 CPE User Manual...
  • Page 53 The tool starts the auto-configuration process of the unit settings. It will change default settings by using the *.ipk file, and then run “reset to factory default” by using default configuration in the file. BreezeMAX Si 4000 CPE User Manual...
  • Page 54 Figure 3-6: Installing Window When the installation is complete, an Installation Success window is displayed. Click OK. Figure 3-7: Installation Succeeded Click Finish. The CPE is now configured with the parameters from the ConfigFile. BreezeMAX Si 4000 CPE User Manual...
  • Page 55 Chapter 3 - Commissioning Configuring the CPE Using the WiMAX Modem Application CD Figure 3-8: Installation Complete BreezeMAX Si 4000 CPE User Manual...

  • Page 56: Operation Verification

    To verify data connectivity, from the end-user's PC or from a portable PC connected to the unit, ping a known device in the network, or connect to a known internet site www.Alvarion.com. This site can be reached by clicking the Alvarion logo on any page in the GUI.

  • Page 57: Chapter 4 - Configuring Setup Parameters

    zzAlvario Chapter Configuring Setup Parameters...
  • Page 58 “Setting Basic Parameters” on page 44  “Setting Password” on page 47  “Setting Device Time Zone” on page 48  “Setting Device Name” on page 50  “Restore to Factory Default Configuration” on page 51  BreezeMAX Si 4000 CPE User Manual...

  • Page 59: Introduction

    Apply: “Configuration setting”. After the configuration is applied, a “Prepare for Reboot” message is displayed. The system performs a reboot and counts 60 seconds. When applying Factory Defaults, a Rebooting message and the 60 seconds countdown are displayed. BreezeMAX Si 4000 CPE User Manual...

  • Page 60: Setting Basic Parameters

    Figure 4-1: Setup - Basic Parameters The following table describes the configurable Basic parameters: Table 4-1: Basic Parameters Parameter Description Default Possible Values Operation Mode BreezeMAX Si 4000 CPE User Manual...
  • Page 61 This IP is used only for SIP/RTCP and RTP messages sent and received by the device’s POTS (plain old telephone service) lines.  Router mode forwards packets based on Layer 3 IP addresses.  None - No forwarding BreezeMAX Si 4000 CPE User Manual...
  • Page 62 (MTU) size in bytes  Manual  Auto (1400) - transmission unit size is 1400 bytes  Manual - enter the value for transmission unit size (Range: 576-1500) NOTE Static IP is not supported by 4Motion equipment. BreezeMAX Si 4000 CPE User Manual...

  • Page 63: Setting Password

    Keep a record of the password in a safe place, in case you will need to restore it. Figure 4-2: Setup - Password To change the login password: Enter a new login password (up to 19 characters) Enter the new password again for verification. Click Apply. BreezeMAX Si 4000 CPE User Manual...

  • Page 64: Setting Device Time Zone

    Universal Time Coordinated, or UTC) based on the time at the Earth’s prime meridian, zero degrees longitude. To display a time corresponding to your local time, select your time zone from the pull-down list. The default is GMT-06.00, for Central Time (USA and Canada.) BreezeMAX Si 4000 CPE User Manual...
  • Page 65 Setting Device Time Zone Auto Adjust for Daylight Saving Time - Select this check-box to set the  daylight saving time if the unit operates in a region that observes daylight saving time. The default is Enabled. BreezeMAX Si 4000 CPE User Manual...

  • Page 66: Setting Device Name

    Current Device Name - Displays the current name of the unit (Default:  WiMAXCPE) New Device Name - Enter a new name for your device (up to 20 ASCII  printable characters) and click Apply. BreezeMAX Si 4000 CPE User Manual...

  • Page 67: Restore To Factory Default Configuration

    Figure 4-5: Setup - Restore to Factory Warning To restore settings to factory defaults, select the checkbox on this page and click Apply to confirm the action. After applying factory defaults, the unit reboots. BreezeMAX Si 4000 CPE User Manual...

  • Page 68: Chapter 5 - Configuring Wifi Parameters

    zzAlvarion_ page Chapter Configuring WiFi Parameters...
  • Page 69 Chapter 5 - Configuring WiFi Parameters In this chapter: “Introduction” on page 54  “WiFi Configuration” on page 55  BreezeMAX Si 4000 CPE User Manual...

  • Page 70: Introduction

    The BreezeMAX Si 4000 model for 3.5 GHz WiMAX band and the BreezeMAX Si 4000 premium model include an IEEE 802.11g and IEEE 802.11b radio interface for local Wi-Fi communications. The Wi-Fi setup pages include configuration options for the radio signal characteristics and Wi-Fi security. BreezeMAX Si 4000 CPE User Manual...

  • Page 71: Wifi Configuration

    Enable WiFi Interface - Enables/disables the Wi-Fi radio  Country Code –The parameter set (list of parameters per country regulations)  by which various parameters are defined (Read-only). Default WiFi Country Code for EU P/N is ETSI. BreezeMAX Si 4000 CPE User Manual...
  • Page 72 Wi-Fi network, there needs to be a mechanism that prevents 802.11b clients from interfering with 802.11g transmissions. This is achieved by sending 802.11b-compatible CTS (Clear to Send) or RTS/CTS (Request to Send / Clear to Send) frames before each transmission. This mechanism BreezeMAX Si 4000 CPE User Manual...
  • Page 73 4000. When enabled, the unit does not include its SSID in beacon messages. This provides a basic level of security, since wireless clients must be configured with the SSID to connect to the BreezeMAX Si 4000. (Default: Disable) BreezeMAX Si 4000 CPE User Manual...

  • Page 74: Wireless Security

    The following security options are available. These options are described in the next sections: 802.1x   » Open System » Shared Key  » BreezeMAX Si 4000 CPE User Manual...
  • Page 75 Open System Authentication (OSA) is a process by which a computer can gain access to a wireless network that uses the Wired Equivalent Privacy (WEP) protocol. With OSA, a computer equipped with a wireless modem can access any BreezeMAX Si 4000 CPE User Manual...
  • Page 76 WPA utilizes 128-bit encryption keys and dynamic session keys to ensure your wireless network's privacy and enterprise security. There are two basic forms of WPA: WPA Enterprise (requires a RADIUS server)  BreezeMAX Si 4000 CPE User Manual...

  • Page 77: Acl (Access Control List) Settings

    The following are examples of a MAC address template that can be used: 00:11:22:33:44:55  001122334455  Select either Disable, Allow or Deny. For the Allow and Deny lists, click Insert to add a MAC address to the list. BreezeMAX Si 4000 CPE User Manual...

  • Page 78: Chapter 6 - Configuring Local Address Parameters

    zzAlvarion_ page Chapter Configuring Local Address Parameters...
  • Page 79 Chapter 6 - Configuring Local Address Parameters In this chapter: “Introduction” on page 64  “DHCP Server” on page 65  “Lease Status” on page 66  “Lease Reservation” on page 67  BreezeMAX Si 4000 CPE User Manual...

  • Page 80: Introduction

    This chapter describes how to configure internal unit parameters such as DHCP server details and leasing parameters. NOTE Any changes to this section should only be carried out by a network administrator familiar with the functionality of these settings. BreezeMAX Si 4000 CPE User Manual...

  • Page 81: Dhcp Server

    DHCP Ending IP Address - Enter the last IP address assigned by the DHCP  server. The default address is 192.168.254.5. DHCP Lease Time - Set the time for renewing the IP Lease. Default: 1 hour.  BreezeMAX Si 4000 CPE User Manual...

  • Page 82: Lease Status

    Host PC MAC Address  IP Address  Remaining Lease Duration (seconds)  Figure 6-2: Lease Status Click Refresh to display the updated information of the client host PC. Click Auto to refresh the information automatically. BreezeMAX Si 4000 CPE User Manual...

  • Page 83: Lease Reservation

     Enabled - Select if to enable or disable a specified IP setting.  Use the Add or Delete buttons to add or clear reserved IPs for leasing. Click Apply to activate your changes. BreezeMAX Si 4000 CPE User Manual...

  • Page 84: Chapter 7 - Setting Advanced Parameters

    zzAlvarion_ page Chapter Setting Advanced Parameters...
  • Page 85 “Security” on page 73  “Firewall” on page 75  “MAC Filter” on page 78  “IP Filter” on page 79  “Port Forwarding/Trigger” on page 81  “Dynamic DNS” on page 84  BreezeMAX Si 4000 CPE User Manual...

  • Page 86: Introduction

    This chapter describes how to configure advanced parameters, such as: Firewall protection, authentication methods, security parameters, filters for blocking the access of unauthorized clients, port forwarding and triggering, and also the Dynamic DNS (Domain Name System) provider. BreezeMAX Si 4000 CPE User Manual...

  • Page 87: Authentication

    WiMAX network. IMPORTANT Do not change parameters in this page unless specifically instructed by your service provider. Figure 7-1: Advanced - Authentication The Authentication page includes the following parameters: BreezeMAX Si 4000 CPE User Manual...
  • Page 88 User Name - Enter the user name supplied by the service provider (Default:  wan mac address@WiMax.com, e.g. 0026824EE12C@WiMax.com). Password - Enter the user password supplied by the service provider). Default:  quickynikynyoky Password Confirmation - Re-enter the user password to confirm it.  BreezeMAX Si 4000 CPE User Manual...

  • Page 89: Security

    (Default: Disabled) Web Login Port from Internet - Define a specific port number for security  access control (the default port number is 8080). Available only if Web Login from Internet is enabled. BreezeMAX Si 4000 CPE User Manual...
  • Page 90 WAN to the unit. To issue a Ping command, enter the destination address and click Ping. The response will be displayed in the area below the Ping button. To access from WAN, use https://CPE_WAN_IP_Address:8080. BreezeMAX Si 4000 CPE User Manual...

  • Page 91: Firewall

    Changes made on this page may affect your internet connection. If you notice an undesirable change in your internet service after making a change to the firewall, you may want to return to the previous setting. Figure 7-3: Advance - Firewall The following configuration parameters are available: BreezeMAX Si 4000 CPE User Manual...
  • Page 92 IP layer, and enables to use encrypted tunnels /traffic between two hosts. » Enable PPTP pass-through - Point to Point Tunneling Protocol. This protocol enables the transfer of data packets of TCP / IP through a foreign BreezeMAX Si 4000 CPE User Manual...
  • Page 93 (by marking the packet with an address suited to the foreign network) » Enable L2TP pass-through - Layer 2 Tunneling Protocol an open standard with mutlivendor interoperability and acceptance. BreezeMAX Si 4000 CPE User Manual...

  • Page 94: Mac Filter

    Enabled - Select this check-box to enable/disable filter for the specific MAC  address. Use the Add or Del buttons to add the address to the filtered group or clear it from the group. Click Apply to activate your changes. BreezeMAX Si 4000 CPE User Manual...

  • Page 95: Ip Filter

    IP Range - Specify an IP address or range on the local network. (Range:  192.168.254.1 to 192.168.254.254) Port Range - Enter the port range to be filtered  Protocol - set the protocol to be filtered: TCP (default) or UDP.  BreezeMAX Si 4000 CPE User Manual...
  • Page 96 Enabled - Select this check-box to enable (default) or disable filtering for the  specific table entry. Use the Add or Del buttons to add the address to the filtered group or clear it from the group. Click Apply to activate your changes. BreezeMAX Si 4000 CPE User Manual...

  • Page 97: Port Forwarding/Trigger

    WAN Port - Enter the range (begin and end ports) for the WAN.  LAN IP - Enter the IP address of the computer from LAN network for which  you open ports in “Port forwarding”. BreezeMAX Si 4000 CPE User Manual...

  • Page 98: Port Trigger

    In the Port Trigger page you can specify up to 15 rules with parameters for Port Triggering. Figure 7-7: Advance - Port Trigger The following configuration parameters are available: BreezeMAX Si 4000 CPE User Manual...
  • Page 99 Enabled - Select this check-box to enable/disable port trigger for the specific  application Use the Add or Del buttons to add a rule to the port triggering group or clear it from the group. Click Apply to activate your changes. BreezeMAX Si 4000 CPE User Manual...

  • Page 100: Dynamic Dns

    When DDNS is enabled, configure the following parameters: » DDNS User Name » DDNS Password » DDNS Host Name DDNS Service Provider - Select the DDNS service provider from the  drop-down list (Default: www.dyndns.org). BreezeMAX Si 4000 CPE User Manual...

  • Page 101: Chapter 8 - Displaying Status Details

    zzAlvarion_ page Chapter Displaying Status Details...
  • Page 102 “Device Status” on page 88  “WiMAX Status” on page 90  “Software Status” on page 95  “Telephony Status” on page 96  “Certificate Status” on page 97  “About” on page 99  BreezeMAX Si 4000 CPE User Manual...

  • Page 103: Introduction

    The Status menu item includes pages containing information on all the features of the device, such as the device currently used software, the Telephony status, WiMAX parameters, certification information, etc. BreezeMAX Si 4000 CPE User Manual...

  • Page 104: Device Status

    WiMAX network to the local network, as defined in “Setting Basic Parameters” on page 44 . Available option: Router. “Setting Basic Connection Mode Connection type for the unit, as defined in Parameters” on page 44 . Available options: DHCP, Static BreezeMAX Si 4000 CPE User Manual...
  • Page 105 Base Station ID number (e.g. 00:01:21:00:03:5A) RSSI Currently received signal strength indication (e.g. 78 dBm) CINR Carrier to Interference-plus-Noise Ratio [in decibels (dB)] (e.g. 13 dB). This value should be maximized for best signal quality. BreezeMAX Si 4000 CPE User Manual...

  • Page 106: Wimax Status

    The WiMAX Status displays a summary of the WiMAX network connection parameters. Figure 8-2: Status - WiMAX Status Click Refresh to display the current WiMAX connection status.  Click Auto to update the status information periodically (every 3 seconds)  BreezeMAX Si 4000 CPE User Manual...
  • Page 107 Maximum uplink transmit power Max RSSI Maximum received signal strength -35 to -100 dBm indication Max CINR Maximum Carrier to Interference-plus-Noise Ratio Connection Time Time (in seconds) during which the unit is connected to the BS BreezeMAX Si 4000 CPE User Manual...
  • Page 108 Packets Number of carried blocks of data BE bytes Total number of bytes sent on Best Effort connection UGS bytes Total number of bytes sent on Unsolicited Grant Service connection BreezeMAX Si 4000 CPE User Manual...
  • Page 109 QPSK DL/UL PDUs  16QAM DL/UL PDUs  64QAM DL/UL PDUs TX Service Flow / Rx Service Flow Type The service flow type Best effort, ERT, NRT, UGS SFID Service flow ID Connection ID BreezeMAX Si 4000 CPE User Manual...
  • Page 110 Chapter 8 - Displaying Status Details WiMAX Status Table 8-2: WiMAX System Parameters (Continued) Parameter Description Possible values DropPackets (Tx only) Number of packets that were dropped DropBytes (Tx only) Number of packets that were dropped BreezeMAX Si 4000 CPE User Manual...

  • Page 111: Software Status

    Management System) - lightweight package management systems that allows for dynamic installation/removal of packages on a running system. NOTE Use this page only upon instructions from Alvarion. Figure 8-3: Status - Software To install an IPKG - Click Browse to load and install an Itsy Package ...

  • Page 112: Telephony Status

    DSP Version - current version of the voice chip in the Data Signal Processor  (DSP). Click Refresh to display the current telephony status.  Click Auto to update the status information periodically (every 3 seconds).  BreezeMAX Si 4000 CPE User Manual...

  • Page 113: Certificate Status

    Do not change parameters in this page unless specifically instructed by your service provider. Figure 8-5: Status - Certificate The page displays the following information in a table: Certificate Serial Number  Issued to  Issued by  BreezeMAX Si 4000 CPE User Manual...
  • Page 114 To add a certificate, click Browse and select the file to load. Click Import to  add the certificate to the list. To remove an editable certificate, click Remove next to the certificate to be  deleted. Some certificates are read-only and cannot be deleted. BreezeMAX Si 4000 CPE User Manual...

  • Page 115: About

    The information includes: Service Provider  Product Name  WAN MAC  LAN MAC  Model ID  Hardware Version  Serial Number  Figure 8-6: Status - About BreezeMAX Si 4000 CPE User Manual...

  • Page 116: Chapter 9 - Configuring Telephony Parameters

    zzAlvarion_ page Chapter Configuring Telephony Parameters...
  • Page 117 Chapter 9 - Configuring Telephony Parameters In this chapter “VoIP Parameters” on page 102  BreezeMAX Si 4000 CPE User Manual...

  • Page 118: Voip Parameters

    If you are having trouble with your voice service, contact Customer Care for support. Do not make changes to these items in an attempt to restore your service. BreezeMAX Si 4000 CPE User Manual...
  • Page 119 User Name - The SIP (Session Initiation Protocol) User name. Its format  depends on the Sip Server Password and Confirm Password - The SIP user Password  User Account - The SIP Account. Its format depends on the Sip Server.  BreezeMAX Si 4000 CPE User Manual...
  • Page 120 Call Block list - set up the numbers as follows:  » Incoming - blocks incoming calls from the listed numbers (up to 50 digits). » Outcoming - blocks outgoing calls from the listed numbers (up to 50 digits). BreezeMAX Si 4000 CPE User Manual...

  • Page 121: Troubleshooting

    zzAlvarion_ page Chapter Troubleshooting...
  • Page 122 Chapter 10 - Troubleshooting In This Chapter: This chapter provides a lists of things to check in case of problems before contacting local Customer Support. BreezeMAX Si 4000 CPE User Manual...
  • Page 123 Forgot or Lost the Password » Set the unit to its default configuration by pressing the reset button on the rear panel for 5 seconds or more. Then use the default password Alvarion to access the management interface. NOTE All user settings will be lost, including WiFi and Voice settings. Voice settings can be reconfigured by contacting Customer Support.
  • Page 124 Be sure the cable is plugged into both the unit and corresponding device.  Verify that the proper cable type is used and its length does not exceed specified limits.  Check the cable connections for possible defects. Replace the defective cable if necessary. BreezeMAX Si 4000 CPE User Manual...
  • Page 125 * WiFi LED (3) in 3.5 GHz models, unused LED in 2.5 GHz models Premium Model WiMAX Signal Strength LEDs (3-5) WiMAX LED (2) VoIP LEDs (7,8) WiFi LED (6) Power LED (1) Figure 10-1: BreezeMAX Si 4000 and BreezeMAX Si 4000 Premium model Front Panel BreezeMAX Si 4000 CPE User Manual...
  • Page 126 zzAlvarion_ page Glossary...
  • Page 127 NAPID is used to filter some BS if the NAPID is not matched. Priority is the customer defined priority scan order. Higher priority will be scanned first. RefID is a result of mapping from IDs into a scan list from the channel plan. BreezeMAX Si 4000 CPE User Manual...
  • Page 128 (made up of two frequencies - high and low) that allows a computer to recognize the tone. Extended Real-time One of the five QoS service types defined in the IEEE 802.16 POLLING SERVICE (ertPS) WiMAX. BreezeMAX Si 4000 CPE User Manual...
  • Page 129 IP Conversion Sublayer A mode in which transmitted packets contain an 802.3 header (IP-CS) Itsy Package Management Itsy Package Management System - a lightweight package System (IPKG, ipkg) management system designed for embedded devices. BreezeMAX Si 4000 CPE User Manual...
  • Page 130 MSCHAPV2 (MS-CHAP. v2) Microsoft version of the Challenge-handshake authentication protocol, version 2. MS-CHAPv2 provides mutual authentication between peers by adding a peer challenge upon the Response packet and an authenticator response on the Success packet. BreezeMAX Si 4000 CPE User Manual...
  • Page 131 (by marking the packet with an address suited to the foreign network) Quadrature Phase Shift A digital modulation scheme that conveys data by changing, or Keying (QPSK) modulating, the phase of a reference signal (the carrier wave). BreezeMAX Si 4000 CPE User Manual...
  • Page 132 Internet telephone calls, multimedia distribution, and multimedia conferences. Simple Network Simple Network Management Protocol: The application Management Protocol protocol in the Internet suite of protocols which offers network (SNMP) management services. BreezeMAX Si 4000 CPE User Manual...
  • Page 133 One of the five QoS service types defined in the IEEE 802.16 (UGS) WiMAX. It is designed to support real-time service flows that generate fixed-size data packets on a periodic basis, such as T1/E1 and Voice over IP without silence suppression. BreezeMAX Si 4000 CPE User Manual...
  • Page 134 The WPA protocol implements the majority of the IEEE 802.11i standard. WPA2 implements the mandatory elements of the 802.11i standard. BreezeMAX Si 4000 CPE User Manual...
  • Page 135 Virtual Private Network A private communications network that is based on the public (VPN) network and uses information security and channeling protocol in order to maintain security of information transferred over the general network. BreezeMAX Si 4000 CPE User Manual...
