Indicator Area

Notebook PCs Indicator Area
The indicator area displays icons that notify you when you receive
messages and indicate whether certain options and features are enabled.
Icon Meaning
Note: This icon is displayed only when voice and data
services are available.
The Signal Strength indicator uses bars to show the intensity of the
radio signal. The number of bars increases as signal strength increases
to a maximum of four bars.
Tip: Optimal signal strength is obtained when the
antenna is perpendicular to the card.
When no bars are shown, no connection is possible for one of these reasons:
Once a connection is established, this icon is replaced by the
transmitting/receiving icon ( ).
3A: The PCS Connection Manager Software (Notebook PCs) 49
Indicator Area Icons
No antenna is attached
You are outside the CDMA network coverage area
The signal strength is too weak
A network or account problem is preventing the
PCS Connection Card from obtaining service
Section 3: Using the PCS Connection Card
