Using the PCS Connection Card Battery Pack

Your PCS Connection Card comes with a partially-charged Lithium Ion
battery, so you may use your card immediately after it is activated.

Assembling the Battery Pack

Battery cover
LiIon battery
Battery
removal
notch
To insert the battery into the battery pack:
Remove the battery cover from the back of the battery pack by sliding
1.
it in the direction of the arrow.
Hold the battery so that the metal contacts on the base of the battery
2.
line up with the metal contacts on the base of the battery bay.
Place the battery into the battery bay, top edge first.
3.
Replace the cover on the back of the battery pack.
4.
Section 2: Installing the PCS Connection Card
30 2B: Installation on Pocket PCs
Battery Pack
Tabs
Battery release
button
Battery bay
