Transmitter Specifications
Type of Multiplexing
Normal Output Power
TX Max Power
Frequency Range
Frequency Stability
Bandwidth
Occupied Bandwidth
Type of Oscillation
Local Oscillator Frequency 1720.87 ~ 1778.37 MHz
Intermediate Frequency
Modulation Method
Waveform Quality
Conducted Spurious
Emission
Common RF Impedance 50 ohm
Transmitter Specifications
Duplex
0.2 W
Over 23dBm (Peak 25dBm)
1851.25 ~ 1908.75 MHz
Under Defined Frequency ±150Hz
1.25 MHz
Under 1.32 MHz
PLL Synthesizer
130.38 MHz
OQPSK
Over 0.944
Over Carrier ±1.25 MHz, -42dBc/30KHz
Section 5: Technical Specifications
5A: Technical Specifications 135
