Hardware Specifications

Interface Type
Common Air Interface
Channel Spacing
Chip set
IF Receiving Chip
IF Transfer Chip
Baud Rate
Transmitting
(Max. Data Rate)
Supply Voltage
Battery
Charger (charging time) Approximately 2.6 hours
Current Consumption:
Sleep / Idle
Average In-Use
Max. (Peak)
Average In-Use Time
Communication Ports
Voice Capability
Hardware Specifications
Compact Flash Type II
CDMA 1xRTT
50KHz
MSM 5105
IFR3000 / S1M8656A
RFT3100
Default: 230,400 bps (changeable)
Forward Link: 153.6 kbps
Reverse Link: 76.8 kbps
3.7V from CF battery pack
3.3V from CF (or PCMCIA) slot
900mAh
About 23mA / 135mA
About 360mA (Tx: +5dBm, Rx: -78dBm)
About 720mA (Tx: +23dBm, Rx: -106.5dBm)
About 3.3 hours (Continuous talk time with 10dBm
transmit power)
About 36 hours (Standby mode)
1 port
Support
Section 5: Technical Specifications
5A: Technical Specifications 133
