The PCS Connection Manager Window

The PCS Connection Manager features its own Custom Main Interface
(CMI) window. It includes these components:
A Menu button in the lower left corner
A Minimize and Close button in the lower right corner
A message area (in the upper left area)
An indicator area (near the middle of the screen)
A button ("GO") used to establish/cancel a connection
message area
menu button
About the Interface
The following application functions are available within the
PCS Connection Manager main window:
Close: Closes the interface.
Go: Initiates a connection.
Minimize: minimizes the interface.
Menu: provides access to tools and settings options.
Stop: Disconnects an active connection.
Connection status: Displays Please insert card, Click "GO" to
connect, Connecting or Connected states.
Signal strength: Visual indicator of signal strength.
3A: The PCS Connection Manager Software (Notebook PCs) 45
PCS Connection Manager Main Window
keypad button
Section 3: Using the PCS Connection Card
indicator area
minimize button
establish/cancel
a connection
close button
