Ordering Information; Bill Of Materials - Analog Devices EVAL-ADM1075EBZ User Manual

UG-304

ORDERING INFORMATION

BILL OF MATERIALS

Table 8.
Reference Designator
C1
C10
C11
C12
C13
C14
C15
C16
C17
C18
C19
C2
C20
C21
C3
C4
C5
C6
C7
C8
C9
Cadc
Ccap
Cov
Cov2
Cplim
Csnb
Css
Ctimer
Ctimer2
Cuvh
Cuvl
Cvin
D_GPO1
D_GPO2
D_INPUT
D_ISO
D_LATCH
D_PWRGD
D_SPLYGD
D1
D10
D2
D3
D4
D5
D6
D7
D8
Description 1
680 µF 100 V
10 µF 10 V
1 µF 25 V
1 µF 25 V
100 nF 50 V
1 µF 25 V
1 µF 25 V
100 nF 50 V
NO POP
1 µF 25 V
100 nF 50 V
100 nF 50 V
NO POP
NO POP
100 nF 50 V
NO POP
1 µF 25 V
1 µF 25 V
100 nF 50 V
100 nF 50 V
100 nF 50 V
100 nF 50 V
1 µF 16 V
100 nF 50 V
10 nF 50 V
NO POP
NO POP
NO POP
470 nF
NO POP
100 nF
100 nF
1 µF 25 V
LED yellow
LED yellow
LED green
LED blue
LED red
LED green
LED green
85 V TVS
NO POP
DIODE- Z_SOD-123
BAT54H
BAT54H
BAT54H
NO POP
NO POP
NO POP
Rev. C | Page 14 of 19
EVAL-ADM1075EBZ User Guide
Stock Code
FEC 9692657
FEC 1833812
FEC 1637035
FEC 1637035
FEC 1692286
FEC 1637035
FEC 1637035
FEC 1692286
NO POP
FEC 1637035
FEC 1692286
FEC 1692286
NO POP
NO POP
FEC 1692286
NO POP
FEC 1637035
FEC 1637035
FEC 1692286
FEC 1692286
FEC 1692286
FEC 1692286
FEC 1288256
FEC 1692286
NO POP
NO POP
NO POP
NO POP
FEC 1828894
NO POP
FEC 1692286
FEC 1692286
FEC 1637035
FEC 1226421
FEC 1226421
FEC 1226376
FEC 8529876
FEC 1328348
FEC 1226376
FEC 1226376
Digikey SMCJ85ABCT-ND
FEC 1228222
FEC 1757814
FEC 1757752
FEC 1757752
FEC 1757752
NO POP
FEC 1431256
FEC 1228222
