TEST PLOTS
Figure 11. Power-Up Profile; Channel 1 = VIN (Yellow); Channel 2 = V
Channel 3 = Gate (Pink); Channel 4 = System Current (Green);
M1 = FET Power (CH2 × CH4) (Orange)
Figure 12. Power-Up into a Fault (TIMER); Channel 1 = VIN (Yellow); Channel 2 =
V
(Blue); Channel 3 = TIMER (Pink); Channel 4 = System Current (Green)
DS
Figure 13. TIMER During a Fault; Channel 1 = VIN (Yellow); Channel 2 = V
(Blue); Channel 3 = TIMER (Pink); Channel 4 = System Current (Green)
(Blue);
Figure 14. Severe OC Event; Channel 1 = VIN (Yellow); Channel 2 = V
DS
Channel 3 = Gate (Pink); Channel 4 = System Current (Green);
Figure 15. Short Circuit Event; Channel 1 = VIN (Yellow); Channel 2 = V
(Blue); Channel 3 = Gate (Pink); Channel 4 = System Current (Green);
Figure 16. Short-Circuit Event (Zoom); Channel 1 = VIN (Yellow); Channel 2 =
DS
V
(Blue); Channel 3 = Gate (Pink); Channel 4 = System Current (Green)
DS
Rev. C | Page 10 of 19
EVAL-ADM1075EBZ User Guide
M1 = FET Power (CH2 × CH4) (Orange)
M1 = FET Power (CH2 × CH4) (Orange)
(Blue);
DS
DS
