SECTION 2:

INTRODUCTION

2.01 Overview

Plasma is a gas which has been heated to an extremely
high temperature and ionized so that it becomes elec-
trically conductive. The plasma arc cutting process uses
this plasma to transfer an electrical arc to the workpiece.
The metal to be cut is melted by the heat of the arc and
then blown away.
Manual 0-4686

2.02 General Specifications

Model Description
Maximum Output
Input Voltage & Phase
Frequency
Input Power 230V 1/3 Phase
Input Power 400V 3 Phase
Input Power 460V 1/3 Phase
Input Fuse 230V ±10% 1Phase
Input Fuse 230V ±10% 3Phase
Input Fuse 400V ±10%
Input Fuse 460V ±10% 1Phase
Input Fuse 460V ±10% 3Phase
No Load Voltage
Load Voltage
Output Current
Post Flow Time
Operating Air Pressure
Maximum Input Air Pressure
Air Flow
System Duty Cycle Rating* at
Ambient Air Temperatures of
40° C / 104° F.
System Duty Cycle Rating* at
Ambient Air Temperatures of
40° C / 104° F.
System Duty Cycle Rating* at
Ambient Air Temperatures of
40° C / 104° F.
Genuine Cutting Capacity
Maximum Cutting Capacity
Dimension (W x D x H)
Net Weight
2-1
C-100A
100 Amps
230V, 1/3 phase
400V, 3 phase
460V, 1/3 phase
50/60Hz
87/45 Amps
(20/18 kVA)
31 Amps
(21.5 kVa)
48/25 Amps
(22/20 kVa)
50 Amp Slow Blow
30 Amp Slow Blow
32 Amp Slow Blow
30 Amp Slow Blow
30 Amp Slow Blow
240V
120V
30 - 100 Amp
10 Seconds
72 psi (.5MPa)
(5 bar)
125 psi (.86MPa)
(8.6 bar)
400 scfh, 6.6 scfm
(188.7 lpm)
35% @ 100Amp
60% @ 85Amp
100% @ 70Amp
1 1/4" (30mm)
1 1/2" (40mm)
12.5" x 27.5" x 20.5"
(318mm x 699mm x
520mm)
122 lbs. (85 kg)
Introduction
