INTRODUCTION

Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
INTRODUCTION

REFRESHER VEHICLE OVERVIEW

Welcome to your new Cushman Refresher. The innovative Refresher® is a mobile, customizable profit-making club-
house.
The Refresher unit is designed for inventory of unopened, pre-packaged, non-perishable foods for distribution through
daily use. It is not intended for long-term food storage or storage of opened food and beverage items. Adherence to local
food handling regulations is required.
Read this entire manual to become familiar with your vehicle and the Refresher unit. Pay particular attention to all
NOTICES, CAUTIONS, WARNINGS and DANGERS.

FEATURES

For operation information on each feature, refer to OPERATING PROCEDURES.

General Information

If the vehicle has accessories that were installed at the factory, some accessories continue to operate with the key
switch in the OFF position.

1. Key and Light Switch

2
1
The key and light switch is on the dash panel. The switch controls the basic elec-
trical system of the vehicle and the lights.

2. Fuel Gauge with Low Oil Pressure Indicator (if equipped)

Located on the dash panel next to the key switch. The fuel gauge indicates the
amount of gasoline in the fuel tank, with 'F' indicating a full tank and 'E' indicat-
ing an empty fuel tank. The fuel gauge is equipped with a low oil pressure indi-
cator. A low engine oil pressure condition is alerted with an indicator light.
3
The low oil pressure indicator light on early model vehicles is located beside
the fuel gauge on the dash, and not part of the fuel gauge.

3. 12-Volt Power Outlet

A 12-volt power outlet, with a rating of 15 amps, is found to the left of the key and light switch. The outlet supplies
continuous power for any accessories that have a 12-volt plug.

4. Direction Selector

The direction selector is on the seat panel and allows the operator to select F
4
(forward) or R (reverse) to control the direction of travel.
The direction selector has a reverse warning buzzer that activates when the
operator selects the R position.

5. Choke

Reverse
Forward
The choke is on the seat panel below the driver seat. The choke helps start the
5
vehicle when the engine is cold.
Refer to the COLD-START section for operation instructions.
