Read all of SAFETY and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.

Neutral Lock

To prevent the driven clutch from turning the rear wheels during
service operations, a neutral lock is located on the direction selec-
tor.
To operate:
Turn the key switch to OFF and lift the seat. Pull out and rotate the
neutral lock pin handle so that the pointed portion of the handle is
to the side of the direction selector cam. Move the direction selec-
tor toward the area between F and R. During that motion the pin
will snap into the hole in the direction selector mounting bracket,
preventing any movement.
When in this position, the direction selector remains locked in the
neutral position. To unlock the direction selector, pull the neutral
lock pin handle out and rotate until the pointed portion of the handle
fits into the hole in the direction selector cam.

Hauling

Make sure you secure the vehicle and all items before you move a vehicle on a trailer.
Never ride or allow anyone to ride on a vehicle being moved on a trailer.
Remove the windshield before you move a vehicle on a trailer.
Make sure all drawers, doors and cabinets are locked. Remove the removable countertop.
Remove all product and content from the unit to avoid shifting.
Maximum speed with canopy top installed is 50 mph (80 kph).
If you move the vehicle on a trailer at highway speeds, the canopy top must be removed and the seat bottom secured.
When you move the vehicle on a trailer below highway speeds, check for tight hardware and cracks in the canopy top at
the mounting points.
The rated capacity of the trailer or truck must be more than the weight of the vehicle and load plus 1000 lbs. (454 kg).
See GENERAL SPECIFICATIONS for the weight of the vehicle.
Secure the vehicle to the trailer with ratchet tie downs.

SERVICE AND MAINTENANCE

Read all notices, cautions and warnings before any type of service operations.
The drive wheels must be lifted and supported on jack stands before you do any service to the
To decrease the risk of engine damage, do not operate the vehicle at full throttle for more than 5
powertrain when the engine is in operation.
seconds with the drive wheels lifted off the ground.
Owner's Guide
MAINTENANCE
Hole in Direction
Selector Cam
Unlocked
B
