Lock icons
The lock icons indicate if the above displayed function can be modified by the standard user in the
main profile. Please note, that the setting is only valid for the profile that you are currently editing. If you
like to complete allow or ban a function from user access you have to apply the settings for all three
profiles.
Open lock = User is able to enable / disable the associated function
Closed lock = User is not allowed to enable / disable the associated function.
Load default icon
Tab this icon to load the default factory settings to the currently active profile (green LED). This
includes the settings of the wireless devices as well as the key mapping.
Key mapping icon
Tab on this icon to open the key mapping menu. There you can change the actions that are
performed when pushing a hardware button.
WiFi icon
Tab on the icon to set the current active profile standard WiFi settings.
WWAN icon
Tab on the icon to set the current active profile standard WWAN settings.
Bluetooth icon
Tab on the icon to set the current active profile standard Bluetooth settings.
GPS icon
Tab on the icon to set the current active profile standard GPS settings.
Question mark icon
Tab on the icon to open the admin help page.
35
