1.4.2

LED Status

Item Status
Battery Green: On
Amber: On
Amber: Blinking
Off
Blue: On
F
Blue: Off
Wi-Fi Blue: On
Blue: Off
1.4.3

Bottom View

15
No Item
15
Kensington lock
16 Pass-through
17 Docking connector
18 Fixation point
Description
Power on / not charging
Power on / charging
Low power < 10%
Power off / charging full / no battery
function switch on
function switch off
Wi-Fi or Bluetooth on
Wi-Fi or Bluetooth off
16
Description
Lock the Fieldbook I1 to a stationary object for security.
Dual antenna pass-through for WLAN, GPS, WWAN
12 pin connector for docking onto a station.
Fixation point for the stylus tether
17 18
