2.5 Installing a SIM Card
The Fieldbook features a micro SIM card slot for mobile broadband connections (no voice). To use mobile broadband
connections you need a working micro SIM card from mobile operator and a WWAN module needs to be integrated into
your Fieldbook (option).
Please note that only micro SIM cards are supported.
Internet access may incur fees. Contact your service provider for details.
Remove all power from the device before installing or removing the SIM card.
Inserting the SIM card
1.
Shut down the Fieldbook (Please refer to chapter 2.4.2 on page 17)
2.
Open the I/O compartment cover on the left side of the Fieldbook
3.
Locate the micro SIM card slot (Please refer to chapter 1.4.5 Side Views on page 15)
4.
Insert the SIM card into the SIM card slot with the cut-off corner going in first, and the gold contacts facing down.
5.
Push the SIM card all the way until it is flush into the SIM card slot.
6.
Close the I/O compartment cover on the left side of the Fieldbook
Removing the SIM card
1.
Shut down the Fieldbook (Please refer to chapter 2.4.2 on page 17)
2.
Open the I/O compartment cover on the left side of the Fieldbook
3.
Locate the micro SIM card slot (Please refer to chapter 1.4.5 Side Views on page 15)
4.
Gently push the SIM card. The SIM card is slightly ejected from the SIM card slot.
5.
Remove the SIM card.
6.
Close the I/O compartment cover on the left side of the Fieldbook
2.6 Installing a SD Card
Use a micro SD card to expand the Fieldbook storage capacity and / or easily transfer files from one to another system.
Please note that only micro SD cards are supported.
Inserting the SD card
1.
Open the I/O compartment cover on the left side of the Fieldbook
2.
Locate the micro SD card slot (Please refer to chapter 1.4.5 Side Views on page 15)
3.
Insert the micro SD card into the card slot with the gold contacts first and facing up.
4.
Push the SD card all the way until it is clicks into place.
5.
Close the I/O compartment cover on the left side of the Fieldbook
18
