Logic Instrument Fieldbook I1 User Manual page 33

brightness step by step. Double click on the controller activates / deactivates the auto-brightness adjustment controlled
by the ambient light sensor. A green controller indicates the active auto-brightness.
step by step.
Airplane mode is a setting when activated, suspends many of the device's signal transmitting
their associated security settings that were defined by the administrator as well as the key
mapping. The green LED indicates which profile is currently active.
The different user profiles could by helpful when the Fieldbook is used by different persons or for different applications.
The profile setting can only be modified via the admin-menu.
Brightness adjustment
Tab the controller and move it to the left (decrease) or to right (increase) to adjust the
screen brightness. You can also use the brightness symbols to increase/decrease the
Volume adjustment
Tab the controller and move it to the left (decrease) or to right (increase) to adjust the
system volume. You can also use the speaker symbols to increase/decrease the volume
Green LED
Components with a green LED are currently activated.
Red LED
Components with a red LED are currently deactivated.
Black LED
Components with a black LED are physically not installed,
are disabled in the BIOS (refer to:"Advanced Menu", page 34) or are defective.
Blue & green or Blue & red LED
The blue LED indicates that the function of this devices is blocked by the administrator.
Blue & green = device can not be deactivated in the main menu.
Blue & red = device can not be activated in the main menu.
Airplane mode
functions, while still permitting use of other functions that do not require signal transmission.
Tab on the icon to enable or disable the Airplane mode.
The enabled Airplane Mode disables WiFi, WWAN and Bluetooth components and protects
them from accidentally switch on.
Screen auto-orientation
The auto-rotation functionality turns the screen automatically when the tablet is turned. That
makes it very easy to switch fast from landscape to portrait mode and vice versa.
User profiles
The FieldControl features 3 user profiles. Each profile contains the pre-defined wireless and
32
