- Page 1 MEC 200 Electro-mechanical sliding gate operator Vertical and horizontal installation Gear movements and worm-gear coupling in oil bath fully mounted on ball bearings Installation manual...
- Page 2 KEEP TO THE DIAGRAMS. Mec 200 is an extremely versatile system and can suit any sliding gate as it can be mounted either vertically or horizontally, and the motor is available in different power specifications such as 0.37 KW (0.5 HP single- and three-phase); 0.73 KW (1.0 HP single- and three-phase);...
- Page 3 MEC 200 VERTICAL - While fixing the rack it is required that the MEC 200 driving gear is not connected with the gate and it can be made run idle by means of the release spanner E17 supplied with the equipment; the gate can be freely moved by hand.
- Page 4 5) Magnetic Thermal 0.03 A, 230 V 50 Hz Mains Circuit Breaker 13) Photocell Receiver POLO 44 (beyond 100 m cable Ø 2.5 mm) 14) Push Buttons PULIN 3 6) Gate operator MEC 200 15) Post with POLO 44 Photocell Receiver 7) Gear rack 16) Post with POLO 44 Photocell Projector...
- Page 5 SINGLE- AND THREE-PHASE FOR SLIDING GATES PLUS AND AUTOMATIONS FITTED WITH LIMIT SWITCHES 230/400V F6=630mA 24V protection PULIN 3 EXT TIME (electric lock and courtesy light) from 2 to 255s TRANSFORMER DIP-SWITCH F4=630mA Transformer PEDESTRIAN protection OPENING TIME from 3 to 30s 4 5 6 7 8 RADIO PLUG-IN...
- Page 6 SINGLE- AND THREE-PHASE FOR SLIDING GATES PLUS AND AUTOMATIONS FITTED WITH LIMIT SWITCHES LOW VOLTAGE ELECTRICAL CONNECTIONS Photocells and Safety Edge: DIP-SWITCH 1: ON: Photocells stop gate while opening, 12 13 reverse it on closing once obstacle is removed 24V (500 mA) OUTPUT (MAX. LOAD: PHOTOCELLS AND OFF: Photocells do not stop gate while 2 PAIRS PHOTOCELLS...
-
Page 7: Pedestrian Opening
SINGLE- AND THREE-PHASE FOR SLIDING GATES PLUS AND AUTOMATIONS FITTED WITH LIMIT SWITCHES ELECTRICAL POWER CONNECTIONS Single- (230V) and Three-phase (400V) Motors: MOTOR RUN TIME DWELL TIME from 5 to 128s OPEN / CLOSE from 5 to 128s Flashing lamp: 19 20 DIP-SWITCH 4 and 7: ON: Lamp is not operating during... - Page 8 PIC. 8 General description: The electronic control panel Elpro 70/3 Plus, new generation, is designed to operate the sliding gate operators MEC 200. Power supply is 230-380V single- and three-phase. It is built in full compliance with the Low Voltage and Electro-Magnetic Compatibility Regulations. Fitting operations are recommended to be carried out by a qualified technician in conformity to the existing safety standards.
- Page 9 70/3 PLUS SINGLE-/THREE-PHASE FOR SLIDING GATE OPERATORS MEC 200 LOW VOLTAGE ELECTRICAL CONNECTIONS Photocell: DIP-SWITCH 1: ON: Photocells stop gate while opening, reverse it on closing once obstacle is 11 12 18 19 removed PHOTOCELL OFF: Photocells do not stop gate while...
- Page 10 70/3 PLUS SINGLE-/THREE-PHASE FOR SLIDING GATE OPERATORS MEC 200 ELECTRICAL POWER CONNECTIONS Single- (230V) and Three-phase (400V) Motors: MOTOR RUN TIME DWELL TIME from 5 to 150s OPEN / CLOSE from 5 to 150s Flashing lamp: 22 23 DIP-SWITCH 4 and 7:...
- Page 11 - It is recommended to fit three-phase operators with a safety device consisting of a switch to cut off power to the low voltage circuit. Connections are in series with the limit switch common terminal (pic. 9). The switch is activated whenever the override spanner is inserted for manual operations or the operator cover is removed.
- Page 12 TORQUE CONTROL AND ADJUSTMENT MEC 200 incorporates an adjustable clutch system for torque control. The system is in an oil bath and can be adjusted to the gate weight. Adjusting is by a screw which is located on one side of the operator (pic.11). A special spanner E17 is provided with the equipment for this purpose: unscrew the locknut;...
-
Page 13: Technical Specifications
Motor rotation speed 1˙380 rpm 1˙380 rpm 1˙380 rpm 1˙380 rpm 1˙380 rpm 20 μF 30 μF Capacitor Intermittent service MEC 200 GEAR BOX Rated torque 40 Nm 40 Nm 80 Nm 80 Nm 110 Nm Gear ratio 1:32 1:32... - Page 14 MEC 200 OVERALL DIMENSIONS MEC 200 HORIZONTAL MEC 200 VERTICAL 1 meter LENGHTS GEAR RACK FIXING BASE PLATE PIC. 13...
- Page 15 FITTING ACCESSORIES FOR INSTALLING MEC 200 MEC 200 VERTICAL MEC 200 HORIZONTAL GEAR RACK FIXING LIMIT SWITCH STRIKING PLATES FOR SCREW FIXING TO THE GATE STEEL GEAR RACK STEEL GEAR RACK 22 x 22 mm THICKNESS WITH FIXING SLOTS NYLON GEAR RACK...
- Page 16 - It is recommended to carefully read the regulations, advice and remarks in the book “Safety Norms”. The growth of MECCANICA FADINI has always been based on the development of guaranteed products thanks to our “TOTAL QUALITY CONTROL” system which ensures constant quality standards, updated knowledge of the European Standards and compliance with their requirements, in view of an ever increasing process of improvement.
