Phoenix Model EXTRA 260-EP Instruction Manual page 4

Instruction Manual
15
Insert the horizontal to the fuselage.
18
Remove the covering.
21
Remove the covering.
24
Mark the shape of the fuselage onto the
27
a1 a2
a1 = a2
Check the vertical.
16
Check the elevator.
19
Glue the horizontal to the fuselage by
Epoxy.
22
Make the slot for the rudder hinge.
25
28
Glue the vertical to the fuselage by Epoxy.
3
EXTRA 260-EP
17
Mark the shape of the fuselage onto the
elevator.
20
Glue the rudder hinge by C.A glue.
23
Insert the hinge into the slot
26
Insert the vertical to the fuselage.
