KIT CONTENTS: We have organized the parts as they come out of the box for better identification
during assembly. We recommend that you regroup the parts in the same manner. This will ensure you
have all of parts required before you begin assembly
AIR FRAME ASSEMBLIES
. (2) Wing halves with ailerons
. (1) Fuselage with canopy.
. (1) Horizontal stabilizer with elevator halves
. (1) Vertical stabilizer with rudder
. (1) Cowling
. (1) Decal sheet
. (1) Instruction manual
MAIN GEAR ASSEMBLY
. (2) Main gear
. (2) Gear retract
. (2) 75mm diameter wheels
. (8) 3mm x 10mm wood screw
. (2) Metal pushrod 1.7mm x 300mm
. (2) Metal connector
. (2) M2 metal clevis
. (2) Silicone tube
. (4) Collar
TAIL GEAR ASSEMBLY
. (1) Tail gear
. (1) 25mm diameter wheel
. (2) Wheel collar
. (2) Plastic clasp
. (2) 2mm x 16mm wood screw
ELEVATOR CONTROL SYSTEM
. (2) Control horn
. (2) Metal clevis M2
. (2) Silicon tube
. (1) Nylon snap keepper
. (1) Domino connector
. (4) 2mm x 30mm screw
. (1) Metal pushrod 1.7mm x 100mm
RUDDER CONTROL SYSTEM
. (1) Control horn
. (2) 2mm x 30mm screw
. (1) Metal clevis M2
. (1) Silicon tube
. (1) Nylon snap keepper

KIT CONTENTS

1
AILERON CONTROL SYSTEM
. (2) Control horn
. (2) Metal clevis M2
. (2) Silicon tube
. (2) Nylon snap keepper
. (4) 2mm x 30mm screw
. (2) Metal pushrod 1.7mm x 180mm
. (8) 2mm x 10mm wood screw
MOTOR MOUNT ASSEMBLY
. (1) Engine mount
. (4) 4mm x 25mm screw
. (4) 8m flat Washer
. (4) 4m flat Washer
. (4) 4mm x 30mm wood screw
. (4) 4m flat Washer
. (8) Nut
FUEL TANK
. (1) Nylon fuel tank
. (1) Metal clunk
. (1) Pre - assembled stopper w/ 3 tube
MISCELLANEOUS ITEMS
. (2) Dihedral
. (2) Wing screw
. (2) Nylon bushing
. (2) 4mm x 30mm nylon screw
. (4) 2.6mm x 10mm wood screw
. (2) Fiber glass wing cover
. (3) Metal pushrod 1.7mm x 800mm
. (1) Tank keeper
. (1) Plastic engine mount
. (2) Wheel cover
. (8) 3mm x 10mm screw
. (4) Metal plate
