Phoenix Model AT6-TEXAN Instruction Manual page 6

2. Remove the covering.
3. Glue the C.A
4. Attach the metal rod to the retract gear.
Clevis
5. Install and secure the retract gear into the wing.
6. Install the cover for the gear.
13
7. Secure the wheel.
14
8. Install the adjustable servo connector to the
Metal pushrod
15
9. Attach the metal rod of the retract gear to the
16
5
servo arm of the servo retract gear.
servo arm and secure it.
17
18
19
20
