Valor 530SAN Installation And Owner's Manual

Direct vent gas fireplace heater with logs or coals
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WARNING: If the information in these
instructions is not followed exactly, a
fire or explosion may result causing
property damage, personal injury or
loss of life.
- Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
-
•
Do not try to light any appliance.
•
Do not touch any electrical switch: do not
use any phone in your building.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call
the fire department.
- Installation and service must be performed
by a qualified installer, service agency or
the gas supplier.
Vous pouvez vous procurer un exemplaire en langue Française de cette brochure chez votre marchand.
Model 530SAN
Model 530SAP
Direct Vent Gas Fireplace Heater
(with Logs or Coals)
Installation and Owner's Manual
Please read this manual before installing and operating this heater
This manual should remain with the homeowner
Manufactured by
MILES INDUSTRIES LTD.
British Columbia, Canada
This appliance may be installed in an
aftermarket permanently located,
manufactured (mobile) home, where not
prohibited by local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
This appliance is a domestic room heating
appliance. It must not be used for any other
purpose such as drying clothes etc.
B-Vent Installations
If this appliance is intended to be installed with a
B-Vent instead of direct vent, discard this
manual. Follow the installation and operating
procedure in the manual supplied with the B-
Vent adapter kit #552BVK.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: the piping and the final gas
connection must be performed by a licensed
plumber or gas fitter in the State of
Massachusetts
4000339/01
