IMB207 LGA1155 ATX Motherboard
2.4

Connectors

Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors on the hardware.
Connector
CN1~2
CN3
CN4
CN5
CN6
CN7
CN8
CN9
CN10
CN11
CN12
CN13
CN14~15
CN16
CN17
CN18
CN19
CN20
CN21
CN22
CN23
CN24
CN25
CN26~28
CN29
CN30
ATX2
CF1
DIMM1~4
FAN1
FAN2
JP11
PCI1~3
SATA1~2
10
Description
DisplayPort 1 and 2 Connectors
COM1 Connector (CN3A) and DVI-I Connector (CN3B)
PS/2 Keyboard and Mouse Connector
HD Audio Jack
USB Port 2 and 3 Stack
USB Port 0 and 1 Stack
Ethernet Port 2 Internal LEDs Connector
Ethernet Port 1 (CN9A) and 2 (CN9B)
Internal Mouse Connector
Ethernet Port 1 Internal LEDs Connector
COM2 Connector
Internal Keyboard Connector
PCI-Express x1 Slots
PCI-Express x4 Slot
COM3 Connector
PCI-Express x16 Slot
COM4 Connector
Digital I/O Port Connector
USB Port 4 and 5 Connector
USB Port 8 and 9 Connector
USB Port 10 and 11 Connector
SMBus Connector
USB Port 6 and 7 Connector
Serial ATA 2.0 port 2, 3 and 4 Connectors
24-pin ATX Power Connector
Internal Power Connector
8-pin +12V ATX Power Connector
TM
CFast Socket
DDRIII DIMM Connectors
CPU Fan Connector
System Fan Connector
Front Panel Connector
PCI 1, 2 and 3 Slots
Serial ATA 3.0 port 0 and 1 Connectors
Board and Pin Assignments
