2.4.18 CFast™ Socket (CF1)
The board is equipped with a CFast
the Serial ATA bus. The socket is specially designed to avoid incorrect installation of
TM
CFast card. When installing or removing CFast
power is off. The CFast
system.
Pin Signal
S1 GND
S2 TX+
S3 TX-
S4 GND
S5 RX+
S6 RX-
S7 GND
2.4.19

Fan Connectors (FAN1 and FAN2)

Fans are always needed for cooling down CPU and system temperature. The board has
two fan connectors. You can find fan speed on BIOS Setup Utility if CPU fan is installed.
For further information, see BIOS Setup Utility: Advanced\HW Monitor\PC Health Status
(refer to section 5.4).
The FAN1 is a CPU fan interface, see table below.
Pin
1
2
3
4
The FAN2 is a system fan interface, see table below.
Pin
1
2
3
18
TM
socket to support CFast
TM
card by default identifies itself as C: or D: drive in your PC
Pin Signal
PC1 NC
PC2 GND
PC3 NC
PC4 NC
PC5 NC
PC6 NC
PC7 GND
PC8 NC
PC9 NC
PC10 NC
PC11 NC
PC12 NC
PC13 3.3V
PC14 3.3V
PC15 GND
PC16 GND
PC17 NC
Signal
GND
+12V level
Rotation detection
Speed control
Signal
GND
+12V level
Sensor
TM
card which is based on
TM
card, please make sure system
Board and Pin Assignments
