IMB207 LGA1155 ATX Motherboard
Appendix B
Digital I/O

Using the Digital Output Function

O 2E 87
O 2E 87
O 2E 07
O 2F 08
O 2E 30
O 2F 02 Setting DIO is active
O 2E E0
O 2F 00 00: The respective DIO is programmed as an output port
O 2E E1
O 2F NN NN: Setting output value
Note:
NN=01 means output value is "00000001", DIO1 is output high, the rest DIO2~DIO8 are output low.

Using the Digital Input Function

O 2E 87
O 2E 87
O 2E 07
O 2F 08
O 2E 30
O 2F 02 Setting DIO is active
O 2E E0
O 2F FF FF: The respective DIO is programmed as an input port
O 2E E1
I 2F Read Input value
57
Digital I/O
