Ap Discovery - Draytek Vigor2920 Series User Manual

Item
Txop
ACM
AckPolicy
4 . 1 4 . 9 A P D i s
4 . 1 4 . 9 A P D i s
Vigor router can scan all regulatory channels and find working APs in the neighborhood.
Based on the scanning result, users will know which channel is clean for usage. Also, it can be
used to facilitate finding an AP for a WDS link. Notice that during the scanning process (about
5 seconds), no client is allowed to connect to Vigor.
This page is used to scan the existence of the APs on the wireless LAN. Yet, only the AP
which is in the same channel of this router can be found. Please click Scan to discover all the
connected APs.
Vigor2920 Series User's Guide
Description
smaller; however, the difference between AC_BE and AC_BK
categories must be greater.
It means transmission opportunity. For WMM categories of
AC_VI and AC_VO that need higher priorities in data
transmission, please set greater value for them to get highest
transmission opportunity. Specify the value ranging from 0 to
65535.
It is an abbreviation of Admission control Mandatory. It can
restrict stations from using specific category class if it is
checked.
Note: Vigor2920 provides standard WMM configuration in the
web page. If you want to modify the parameters, please refer to
the Wi-Fi WMM standard specification.
"Uncheck" (default value) the box means the AP router will
answer the response request while transmitting WMM packets
through wireless connection. It can assure that the peer must
receive the WMM packets.
"Check" the box means the AP router will not answer any
response request for the transmitting packets. It will have
better performance with lower reliability.
c o v e r y
c o v e r y
358
