Available settings are explained as follows:
Item
Name
Address Type
MAC Address
Start IP Address
End IP Address
Subnet Mask
Invert Selection
3. After finishing all the settings here, please click OK to save the configuration.
Description
Type a name for this profile. Maximum 15 characters are
allowed.
Determine the address type for the IPv6 address.
Select Single Address if this object contains one IPv6
address only.
Select Range Address if this object contains several IPv6s
within a range.
Select Subnet Address if this object contains one subnet
for IPv6 address.
Select Any Address if this object contains any IPv6
address.
Select Mac Address if this object contains Mac address.
Type the MAC address of the network card which will be
controlled.
Type the start IP address for Single Address type.
Type the end IP address if the Range Address type is
selected.
Type the subnet mask if the Subnet Address type is
selected.
If it is checked, all the IPv6 addresses except the ones listed
above will be applied later while it is chosen.
