This router allows you to create multi-VLAN for different purposes of data transferring.
Simply go to WAN and select Multi-VLAN.
G e n e r a
G e n e r
The system allows you to set up to eight channels for multi-VLAN.
Available settings are explained as follows:
Item
Channel
Enable
Add Tag
Priority
After finishing all the settings here, please click OK to save the configuration.
W A N l
W A N l
They are provided for router-borne application such as TR-069. The settings must be applied
and obtained from your ISP. For your special request, please contact with your ISP and then
click WAN link of Channel 5, 6 or 7 to configure your router.
Vigor2920 Series User's Guide
A N
A N
l
a l
Description
Display the number of each channel.
Check this box to enable that channel. The channels that you
enabled here will be shown in the Multi-VLAN channel drop
down list on the web page of Internet Access. Though you can
enable eight channels in this page, yet only one channel can be
chosen on the web page of Internet Access.
To identify the usage of VLAN, check this box to invoke this
setting. And type the number for VLAN ID (number).
To add the packet priority number for such VLAN. The range
is from 0 to 7.
i n k f o r C h a n n e l 5 ,
i n k f o r C h a n n e l 5 ,
6 a n d 7
6 a n d 7
