Item
Prioritize
Limited_bandwidth
Ratio
E d i t t h
E d i t t h
1. The first three (Class 1 to Class 3) class rules can be adjusted for your necessity. To add,
edit or delete the class rule, please click the Edit link of that one.
2. After you click the Edit link, you will see the following page. Now you can define the
name for that Class. In this case, "Test" is used as the name of Class Index #1.
Available settings are explained as follows:
Item
Name
Tag packets as
NO
Vigor2920 Series User's Guide
Description
be impacted by the uploading TCP ACK, you can check this
box to push ACK of upload faster to speed the network traffic.
The ratio typed here is reserved for limited bandwidth of UDP
application.
e C l a s s R u l e f o r Q
e C l a s s R u l e f o r Q
o S
o S
Description
Display the name of such class.
Check the box to tag the packets with the header selected in
the drop down list for this class.
Display the number of the rules defined for such rule.
