Item
Window
Authentication
Landing Page
Index (1-15) in Schedule
Setup
Enable Time Quota
Description
on the screen with time remaining for connection if Idle
Timeout is set. However, the system will update the time
periodically to keep the connection always on. Thus, Idle
Timeout will not interrupt the network connection.
Any user (from LAN side or WLAN side) tries to connect to
Internet via Vigor router must be authenticated by the router
first. There are three ways offered by the router for the user to
choose for authentication.
Web – If it is selected, the use can type the URL of the router
from any browser. Then, a login window will be popped up
and ask the user to type the user name and password for
authentication. If succeed, a Welcome Message (configured in
User Management >> General Setup) will be displayed.
After authentication, the destination URL (if requested by the
user) will be guided automatically by the router.
Alert Tool – If it is selected, the user can open Alert Tool and
type the user name and password for authentication. A window
with remaining time of connection for such user will be
displayed. Next, the user can access Internet through any
browser on Windows. Note that Alert Tool can be downloaded
from DrayTek web site.
Telnet – If it is selected, the user can use Telnet command to
perform the authentication job.
When a user tries to access into the web user interface of
Vigor2920 series with the user name and password specified in
this profile, he/she will be lead into the web page configured in
Landing Page field in User Management>>General Setup.
Check this box to enable such function.
You can type in four sets of time schedule for your request. All
the schedules can be set previously in Application >>
Schedule web page and you can use the number that you have
set in that web page.
Time quota means the total connection time allowed by the
router for the user with such profile. Check the box to enable
the function of time quota. The first box displays the remaining
time of the network connection. The second box allows to type
the number of time (unit is minute) which is available for the
user (using such profile) to access Internet.
– Click this box to set and increase the time quota for
such profile.
– Click this box to decrease the time quota for such
profile.
Note: A dialog will be popped up to notify how many
time remained when a user accesses into Internet through
Vigor router successfully.
