General Setup - Draytek Vigor2920 Series User Manual

the confidential information leakage. For a more flexible deployment, you may add filters of
MAC addresses to isolate users' access from wired LAN.
Manage Wireless Stations - Station List will display all the station in your wireless network
and the status of their connection.
Below shows the menu items for Wireless LAN.
4 . 1 4 . 2 G e n e r a
4 . 1 4 . 2 G e n e r a
By clicking the General Settings, a new web page will appear so that you could configure the
SSID and the wireless channel. Please refer to the following figure for more information.
Available settings are explained as follows:
Item
Enable Wireless LAN
Mode
Vigor2920 Series User's Guide
l S e t u p
l S e t u p
Description
Check the box to enable wireless function.
At present, the router can connect to 11b Only, 11n Only, 11g
344
