Available settings are explained as follows:
Item
Mode
WPA
Description
There are several modes provided for you to choose.
Note: You should also set RADIUS Server simultaneously if
802.1x mode is selected.
Disable - Turn off the encryption mechanism.
WEP-Accepts only WEP clients and the encryption key should
be entered in WEP Key.
WEP/802.1x Only - Accepts only WEP clients and the
encryption key is obtained dynamically from RADIUS server
with 802.1X protocol.
WPA/802.1x Only- Accepts only WPA clients and the
encryption key is obtained dynamically from RADIUS server
with 802.1X protocol.
WPA2/802.1x Only- Accepts only WPA2 clients and the
encryption key is obtained dynamically from RADIUS server
with 802.1X protocol.
Mixed (WPA+WPA2/802.1x only) - Accepts WPA and
WPA2 clients simultaneously and the encryption key is
obtained dynamically from RADIUS server with 802.1X
protocol.
WPA/PSK-Accepts only WPA clients and the encryption key
should be entered in PSK.
WPA2/PSK-Accepts only WPA2 clients and the encryption
key should be entered in PSK.
Mixed (WPA+ WPA2)/PSK - Accepts WPA and WPA2
clients simultaneously and the encryption key should be
entered in PSK.
The WPA encrypts each frame transmitted from the radio
using the key, which either PSK (Pre-Shared Key) entered
manually in this field below or automatically negotiated via
802.1x authentication. Either 8~63 ASCII characters, such as
012345678(or 64 Hexadecimal digits leading by 0x, such as
"0x321253abcde...").
Type - Select from Mixed (WPA+WPA2) or WPA2 only.
Pre-Shared Key (PSK) - Either 8~63 ASCII characters, such
as 012345678..(or 64 Hexadecimal digits leading by 0x, such
