LED
ACT (Activity)
USB
CSM
WLAN
WAN1/2
Line
Phone 1/2
LED on Connector
WAN1/
WAN2 (Giga)
GigaLAN
1/2/3/4
2 0 V n
2 0 V n
Status
Blinking
Off
On
Blinking
On
On
Blinking
On
Blinking
On
Off
On
Off
Blinking
Left LED On
(Green)
Off
Blinking
Right LED On
(Green)
Off
Left LED On
(Green)
Off
Blinking
Right LED On
(Green)
Off
Explanation
The router is powered on and running normally.
The router is powered off.
USB device is connected and ready for use.
The data is transmitting.
The profile(s) of CSM (Content Security
Management) for IM/P2P, URL/Web Content Filter
application can be enabled from Firewall
>>General Setup. (Such profile must be
established under CSM menu).
Wireless access point is ready.
It will blink slowly while wireless traffic goes
through.
If ACT and WLAN LEDs blink quickly and
simultaneously when WPS is working, and it will
return to normal condition after two minutes. (You
need to setup WPS within 2 minutes.)
The WAN1 or WAN2 connection is ready.
It will blink while transmitting data.
A PSTN phone call comes (in and out). However,
when the phone call is disconnected, the LED will
be off.
There is no PSTN phone call.
The phone connected to this port is off-hook.
The phone connected to this port is on-hook.
A phone call comes.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps when left
LED is on.
The port is connected.
The port is disconnected.
The data is transmitting.
The port is connected with 1000Mbps.
The port is connected with 10/100Mbps when left
LED is on.
