Datamax W-Class Maintenance Manual page 181

HD Cutter Option, W-8306 (P/N 24-2436-01)
ITEM NUMBER PART NUMBER
1
2
3
4
5
7
8
9
11
12
13
14
15
16
17
18
19
20
Mechanism Detail (Item Number 1, P/N 17-3054-01)
ITEM NUMBER PART NUMBER
1 DPO17-2726-40
2 DPO17-2726-41
3 DPO17-2726-42
4 DPO17-2726-43
5 DPO17-2726-44
6 DPO17-2726-50
7 DPO17-2726-51
8 DPO17-2726-52
9 DPO17-2726-53
10 DPO17-2726-54
11 DPO17-2726-55
12 DPO17-2726-56
13 DPO10-2514-06
14 DPO10-2514-01
17-3054-01 GUILLOTINE CUTTER MECHANISM
11-5568-02 CUTTER MOUNTING BRACKET
17-3058-01 TENSION CATCH
15-3003-02 COVER CUTTER
15-3004-01 CUTTER HINGE
51-2374-00 CCA CUTTER
11-5625-01 COVER PLATE - SMALL
11-5629-01 COVER PLATE
10-2518-01 WASHER FLAT SS
10-2534-07 SCREW PAN HD PH M3X.5X4MM
24-2642-01 ASSY CUTTER MOTOR W-CLASS
130919 SCREW 4-40 X 3/8 PHIL PH EXT/S
10-2970-01 SCREW FL THD M3 X 6
17-0168-01 CABLE CLAMP
10-3086-01 NUT HEX SELF-LOCKING M3 CRES
32-2276-01 ASSY CUTTER CONTROL CABLE (not shown in drawing)
10-2105-03 SCREW M3X6 PAN HEAD
10-3120-01 SCREW SET M3X3 CUP POINT
MOVING BLADE
FIXED BLADE
ASSY, FRAME
ASSY, MOVING BRACKET
SHAFT
SHAFT, IDLER
GEAR, IDLER
DRIVE GEAR
LINK
ROLLER
SPRING
GEAR, PINION
SCREW FLTHD M3 X 16
SCREW FLTHD M3 X 6
Options
DESCRIPTION
DESCRIPTION
5-77
