8. Pull the Drive Motor slightly within the Drive Motor Bracket to slip the Drive Belt over the Drive
Gear.
9. After allowing the Tensioner Spring to set the Drive Belt tension, tighten the Drive Motor Mounting
Screws.
10. Referring back to Section 4.4, position the Drive Motor Assembly for mounting in the printer and re-
route the Timing Belts around the proper pulleys.
11. Start, but do not tighten both Motor Bracket Mounting Screws and the Lower Belt Tensioner Screw.
12. Reattach the Tensioner Springs to both the Upper and Lower Tensioner assemblies.
13. Allow the Tensioner Springs to adjust the belts.
14. After ensuring that the Timing Belts are properly placed, tighten both Motor Bracket Mounting
Screws, both Upper Belt Tensioner screws, and the Lower Belt Tensioner Screw.
15. Reconnect the Drive Motor harness to connector J6 on the power supply board.
16. Plug in and turn 'On' the printer. With media loaded, press the FEED key several times. Recheck the
belt tension. If necessary, repeat beginning with Step 13; otherwise continue.
17. Turn 'Off' and unplug the printer.
18. Replace the Electronics Cover; see Section 4.1.
Removal and Replacement
