Datamax W-Class Maintenance Manual page 195

Peel Mechanism, W-8306 (P/N 78-2207-01)
ITEM NUMBER PART NUMBER
1
3
4
8
9
10
11
12
13
15
16
17
18
19
20
10-0307-01 RETAINING RING .125D
10-2889-01 SCREW 4-40X 1/4 PHIL FLT HD
10-0447-01 E RING .188 DIA SHAFT
11-5025-01 BRACKET ROLLER FRONT
11-5026-01 BRACKET ROLLER REAR
12-2798-01 SHAFT ROLLER
12-2453-01 SHAFT LATCH
16-2277-01 BLOCK SLIDE
16-2278-01 BLOCK LATCH
17-2459-01 SPRING COMPRESSION .042 W.D.
16-2349-01 ROLLER - CLAMP
12-2551-01 SHAFT HINGE
12-2610-02 BAR PEEL
10-2259-01 SCREW PANHD 2-56 X .31 LG
10-2820-01 WASHER LOCK #2
Options
DESCRIPTION
5-91
