4.12 Fuse Replacement

Only use a replacement fuse with the rating and type as the original fuse; failure to comply could
cause serious damage, including fire.
CAUTION
Removal:
1. Turn 'Off' and unplug the printer.
2. Remove the Electronics Cover from the printer; see Section 4.1.
3. Remove the two top screws on the Power Supply Cover.
4. Carefully pull the Power Supply Cover outward slightly to access and remove the two bottom screws,
then remove the cover.
5. Locate the open fuse and remove it using a Fuse Puller.
Removal and Replacement
4-30
