Mechanical Specifications
Figure 4-2. Itanium
IHS Height (See Note)
Substrate Height (See Note)
611 x
All dimensions are measured in mm. Not to scale.
NOTE:
Processor
900 MHz (1.5 MB)
1.0 GHz (3 MB)
1.3 GHz (3 MB)
1.4 GHz (4 MB)
1.5 GHz (4 MB/6 MB)
1.6 GHz (6 MB/9 MB)
1.66 GHz (6 MB/9 MB)
70
®
2 Processor Package
48.26
42.50
38.50
1.43
0.00
2.03
28 x 1.27 Pitch
Ø
0.305 Pins
IHS
Height
5.575
5.575
5.825
5.825
5.825
5.825
5.825
90.00
42.50
38.50
Top View
Side View
34.29
Bottom View
Substrate
Units
Height
3.397
mm
3.397
mm
3.447
mm
3.447
mm
3.447
mm
3.447
mm
3.447
mm
Integrated Heat Spreader
Processor Package Substrate
Interposer
Pins
25 x 1.27 Pitch
30.48
000655g
Datasheet
