Intel Itanium 2 Processor Datasheet page 66

Pinout Specifications
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 14 of 15)
Pin Name
GND
BPM0#
GND
BPM4#
GND
GND
TERMB
ID6#
RS0#
REQ0#
REQ3#
SBSY#
LOCK#
N/C
BPRI#
TRST#
BPM2#
GND
PMI#
GND
TERM
OUTEN
GND
RSP#
GND
INIT#
GND
REQ1#
GND
REQ4#
GND
TRDY#
GND
BR0#
GND
BR3#
GND
PPODGD#
GND
LINT0
LINT1
66
System Bus
Signal Name
GND
BPM0#
GND
BPM4#
GND
GND
FSBT2
IDA6#/IDB6#
RS0#
REQA0#/LEN0#
ASZ0#/DSZ0#
SBSY#
LOCK#
BPRI#
TRST#
BPM2#
GND
PMI#
GND
FSBT
OUTEN
GND
RSP#
GND
INIT#
GND
WSNP#, D/C#/LEN1#
GND
ASZ1#/DSZ1#
GND
TRDY#
GND
BREQ0#
GND
BREQ3#
GND
PPODGD#
GND
INT
NMI
Pin
Input/Output
Location
AD21 IN
AD22 IN/OUT
AD23 IN
AD24 IN/OUT
AD25 IN
AE02 IN
AE03
AE05 IN
AE07 IN
AE09 IN/OUT
AE11 IN/OUT
AE13 IN/OUT
AE15 IN/OUT
AE17
AE19 IN
AE21 IN
AE23 IN/OUT
AE24 IN
AE25 IN
AF01 IN
AF02 IN
AF04 IN
AF05 IN
AF06 IN
AF07 IN
AF08 IN
AF09 IN
AF10 IN/OUT
AF11 IN
AF12 IN/OUT
AF13 IN
AF14 IN
AF15 IN
AF16 IN/OUT
AF17 IN
AF18 IN
AF19 IN
AF20 OUT
AF21 IN
AF22 IN
AF24 IN
Notes
Power pod signal
Power pod signal
