Intel Itanium 2 Processor Datasheet page 59

Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 7 of 15)
Pin Name
D053#
D056#
VCTERM
D052#
D081#
VCTERM
D088#
D082#
VCTERM
D112#
D116#
VCTERM
D113#
GND
D020#
GND
STBP1#
GND
D028#
GND
D048#
GND
STBP3#
GND
D051#
GND
D084#
GND
STBP5#
GND
D086#
GND
D118#
GND
STBP7#
GND
D115#
GND
VCTERM
D023#
GND
Datasheet
System Bus Pin
Signal Name Location
D53# L09
D56# L11
VCTERM L12
D52# L13
D81# L15
VCTERM L16
D88# L17
D82# L19
VCTERM L20
D112# L21
D116# L23
VCTERM L24
D113# L25
GND M01
D20# M02
GND M03
STBP1# M04
GND M05
D28# M06
GND M07
D48# M08
GND M09
STBP3# M10
GND M11
D51# M12
GND M13
D84# M14
GND M15
STBP5# M16
GND M17
D86# M18
GND M19
D118# M20
GND M21
STBP7# M22
GND M23
D115# M24
GND M25
VCTERM N02
D23# N03
GND N04
Pinout Specifications
Input/Output Notes
IN/OUT
IN/OUT
IN
IN/OUT
IN/OUT
IN
IN/OUT
IN/OUT
IN
IN/OUT
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN
IN/OUT
IN
59
