Intel Itanium 2 Processor Datasheet page 54

Pinout Specifications
Table 3-2. Pin/Signal Information Sorted by Pin Location (Sheet 2 of 15)
Pin Name
N/C
GND
SMSD
GND
SMSC
GND
VCTERM
GND
N/C
VCTERM
D002#
GND
D000#
VCTERM
D035#
GND
D033#
VCTERM
N/C
GND
N/C
VCTERM
D073#
GND
D070#
VCTERM
D099#
GND
D097#
VCTERM
N/C
GND
D004#
GND
D003#
GND
D005#
GND
D037#
GND
D034#
54
System Bus Pin
Signal Name Location
B20
GND B21
SMSD B22
GND B23
SMSC B24
GND B25
VCTERM C01
GND C02
C03
VCTERM C04
D02# C05
GND C06
D00# C07
VCTERM C08
D35# C09
GND C10
D33# C11
VCTERM C12
C13
GND C14
C15
VCTERM C16
D73# C17
GND C18
D70# C19
VCTERM C20
D99# C21
GND C22
D97# C23
VCTERM C24
C25
GND D01
D04# D02
GND D03
D03# D04
GND D05
D05# D06
GND D07
D37# D08
GND D09
D34# D10
Input/Output Notes
IN
IN/OUT SMBus signal
IN
IN SMBus signal
IN
IN
IN
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
IN
IN/OUT
Datasheet
